Wye (1814). Scale 1:48. Plan showing the froe and aft platforms, showing the magazines and storerooms for building Wye (1814), a 28-gun, Sixth Rate Sloop, at Redbridge by Messers Hobbs & Co. Initialled JT and RS (Surveyors of the Navy)
17th September 1813
National Maritime Museum

Wye (1814). Scale 1:48. Plan showing the inboard profile plan, with alterations for building Wye (1814), a 28-gun, Sixth Rate Sloop, at Redbridge by Messers Hobbs & Co. Signed H[enry] Peake, J[oseph] Tucker, R[obert] Seppings (Surveyors of the Navy) A
17th September 1813
National Maritime Museum

Wye (1814). Scale 1:48. Plan showing the lower deck showing accomadation and storerooms for building Wye (1814), a 28-gun, Sixth Rate Sloop at Redbridge by Messers Hobbs & Co. Initialled H[enry].P[eake]., J[oseph].T[ucker]., R[obert].S[eppings].(Surve
17th September 1813
National Maritime Museum

Wye (1814). Scale 1:48. Plan showing the quarter deck and forecastle with modifications for building Wye (1814), a 28-gun, Sixth Rate Sloop at Redbridge by Messers Hobbs & Co. Initialled H[enry].P[eake]., J[oseph].T[ucker]., R[obert].S[eppings].(Surve
17th September 1813
National Maritime Museum

Wye (1814). Scale 1:48. Plan showing the upper deck plan, showing the method of attaching the beams to the sides and modifications to the pumps for building Wye (1814), a 28-gun, Sixth Rate Sloop at Redbridge by Messers Hobbs & Co. Initialled H[enry].
17th September 1813
National Maritime Museum
