Achates (captured 1809). Scale: 1:48. Plan showing the body plan with stern board outline and some decoration detail, the sheer lines with inboard detail and figurehead, and the longitudinal half-breadth for Achates (captured 1809), a captured French Bri
14 August 1810
National Maritime Museum

Achates (captured 1809). Scale: 1:48. Plan showing the upper deck and lower deck with platforms for Achates (captured 1809), a captured French Brig as fitted at Deptford Dockyard as a 16-gun Brig. Signed by Robert John Nelson [Master Shipwright, Deptfor
14 August 1810
National Maritime Museum

Salisbury (1814). Scale: 1:48. Plan showing the body plan, sheer lines and longitudinal half-breadth for building Salisbury (1814), a 50-gun Fourth Rate, two-decker, at Deptford Dockyard. Signed by William Rule [Surveyor of the Navy, 1793-1813]
14 August 1810
National Maritime Museum

Salisbury (1814). Scale: 1:48. Plan showing the framing profile (disposition) for building Salisbury (1814), a 50-gun Fourth Rate, two-decker, at Deptford Dockyard. Signed by William Rule [Surveyor of the Navy, 1793-1813].
14 August 1810
National Maritime Museum
