30 ft Pinnace. Scale: 1:24. Plan showing the body plan, profile, and longitudinal half-breadth for a 12-oared 30 ft Pinnace. A poor paper dyeline copy of ZAZ7198.3 (see also ZAZ7198 for the original, and ZAZ7198.2 for another dyeline copy).
Original dated: 6 February 1840; tracing dated February 1951
National Maritime Museum

30 ft Pinnace. Scale: 1:24. Plan showing the body plan, profile, and longitudinal half-breadth for a 12-oared 30 ft Pinnace. This is the original plan from which ZAZ7198.3 was traced in 1951, and ZAZ7198.1 and ZAZ7198.2 are dyeline copies of the tracin
Dated: 6 February 1840
National Maritime Museum

30 ft Pinnace. Scale: 1:24. Plan showing the body plan, profile, and longitudinal half-breadth for a 12-oared 30 ft Pinnace. A poor paper dyeline copy of ZAZ7198.3 (see also ZAZ7198 for the original, and ZAZ7198.1 for another dyeline copy).
Original dated: 6 February 1840; tracing dated February 1951
National Maritime Museum

30 ft Pinnace. Scale: 1:24. Plan showing the body plan, profile, and longitudinal half-breadth for a 12-oared 30 ft Pinnace. Two paper dyeline copies made from this tracing: ZAZ7198.1 and ZAZ7198.2. The plan was traced from an original, reference ZAZ71
Original dated: 6 February 1840; tracing dated February 1951
National Maritime Museum
