'Worcester' (1769); 'Lion' (1777) [alternative spelling: Lyon]. Scale: 1:48. Plan showing the orlop deck with fore and aft platforms for 'Worcester' (1769), and with alterations dated September 1805 for 'Lion' (1777
11 April 1768
National Maritime Museum

'Worcester' (1769); 'Stirling Castle' (1775); 'Lion' (1777) [alternative spelling: Lyon]. Scale: 1:48. Plan showing the inboard profile proposed (and approved) for 'Worcester' (1769), a 64-gun Third Rate, two-decker
April 1768
National Maritime Museum

Java (1815). Scale: 1:48. Plan showing the inboard profile for Java (1815), a 52-gun Fourth Rate, large Frigate building at Plymouth Dockyard. The plan includes references relating to the construction. Signed by Robert Seppings [Surveyor of the Navy, 1
11 April 1815
National Maritime Museum

Java (1815). Scale: 1:48. Plan showing the inboard profile illustrating the riders for Java (1815), a 52-gun Fourth Rate, large Frigate. The plan includes later alterations, which were sent to Plymouth for fitting the magazine and sail room in accordanc
11 April 1815
National Maritime Museum

Java (1815). Scale: 1:48. Plan showing the lower deck illustrating the cabin layout for Java (1815), a 52-gun Fourth Rate, large Frigate, building at Plymouth Dockyard.
11 April 1815
National Maritime Museum

Java (1815). Scale: 1:48. Plan showing the spar deck (quarterdeck and forecastle with enclosed waist) for Java (1815), a 52-gun Fourth Rate, large Frigate, building at Plymouth Dockyard.
11 April 1815
National Maritime Museum

Java (1815). Scale: 1:48. Plan showing the upper deck for Java (1815), a 52-gun Fourth Rate, large Frigate, building at Plymouth Dockyard.
11 April 1815
National Maritime Museum

Two schooners, close-hauled, with a small boat. original art: drawing
11 Apr 1832
National Maritime Museum

. Inboard profile plan
11 Apr 1942
National Maritime Museum
