Cambridge (1755). Scale: 1:72. A plan showing the body plan, sheer lines, and the longitudinal half-breadth for Cambridge (1755), an 80-gun Third Rate, three-decker. Note the date is when she was designed and the keel laid at Deptford Dockyard. Reverse s
1750
National Maritime Museum

'Royal Sovereign' (1701), 'Victory' (1738), Unnamed 1745 Establishment 100-gun First Rate three-decker. Scale: 1;48. A plan showing the longitudinal half-breadth, sheer lines below water line and the midship bend comparisons between th
May 1750
National Maritime Museum

'Namur' (1756). Scale: 1:48. A plan showing the body plan, sheer lines, and longitudinal half-breadth for 'Namure' (1756), a 90-gun First Rate three decker. Signed and attested by John Clevland [Secretary to the Admiralty].
12 July 1750
National Maritime Museum

'Dunkirk' (1754). Scale: 1:48. A plan showing the body plan, sheer lines, and the longitudinal half-breadth for 'Dunkirk' (1754), a 60-gun Fourth Rate two-decker. Signed by Joseph Allin [Surveyor of the Navy, 1749-1755].
18 July 1750
National Maritime Museum

'Neptune' (1756). No scale. A plan showing the body plan, sheer lines with some inboard detail and figurehead (in pencil) and the longitudinal half-breadth for 'Neptune' (1756), a 90-gun First Rate, three-decker. Signed by Joseph Al
18 July 1750
National Maritime Museum
