'Deptford' (proposed 1745). Scale: 1:48. A plan showing the body plan, sheer lines, and longitudinal half-breadth proposed by the Surveyor of the Navy (in green ink), and by the Master Shipwrights of the Royal Dockyards, for 'Deptford'
circa November 1745
National Maritime Museum

'Eagle' (1745). Scale 1:48. A plan showing the body plan, sheer lines with inboard detail, and the longitudinal half-breadth for 'Eagle' (1745), a 1741 Establishment 60-gun Fourth Rate, two-decker.
1745
National Maritime Museum

Unnamed 100-gun First Rate, three-decker (1745). Scale: 1:144. A plan showing an incomplete rigging plan for an unnamed 100-gun First Rate, three-decker (1745). This plan is possibly generic for the 1745 Establishment built 100-gun First Rates.
1745
National Maritime Museum

Unnamed 24-gun Sixth Rate (1745). Scale: 1:144. A plan showing an incomplete rigging plan with figurehead for an unnamed 24-gun Sixth Rate (1745). This plan is possibly generic for the 1745 Establishment built 24-gun Sixth Rates.
1745
National Maritime Museum

Unnamed 50-gun Fourth Rate (1745). Scale: 1:144. A plan showing an incomplete rigging plan with figurehead for an unnamed 50-gun Fourth Rate, two-decker (1745). This plan is possibly generic for the 1745 Establishment built 50-gun Fourth Rates.
1745
National Maritime Museum

Unnamed 80-gun Third Rate, three-decker (1745). Scale: 1:144. A plan showing the rigging plan with figurehead for an unnamed 80-gun Third Rate, three-decker (1745). This plan is possibly generic for the 1745 Establishment built 80-gun Third Rate.
1745
National Maritime Museum

Unnamed 90-gun Second Rate, three-decker (1745). Scale: 1:144. A plan showing an incomplete rigging plan with figurehead for an unnamed 90-gun Second Rate, three-decker (1745). This plan is possibly generic for 1745 Establishment built 90-gun Second Rates
1745
National Maritime Museum

Unnamed proposed 64-gun Third Rate, two-decker (1745). Scale: 1:48. A plan showing the body plan, sheer lines, and longitudial half breadth for an unnamed 64-gun Third Rate, two-decker (1745), proposed by Joshua Allin in 1745. Signed by Joseph Allin [Sur
