'Sweepstakes' (1709). Scale: 1:48. A plan showing the body plan, basic sheer lines (no water lines), and longitudinal half-breadth for 'Sweepstakes' (1709), a captured French 40-gun Fifth Rate, two-decker.
Early 18th Century
National Maritime Museum

'Ipswich' (1694). Scale: 1:48. A plan showing the body plan, sheer lines with inboard detail and figurehead, the arrangement of stern and lanterns, and the longitudinal half-breadth with deck detail for 'Ipswich' (1694) a 70-gun Third
2 September 1712
National Maritime Museum

'Deptford' (1732). Scale: 1:48. A plan showing the body plan with stern board outline, the sheer lines, and logitudinal half-breadth for 'Deptford' (1732), a 60-gun Third Rate, later Fourth Rate, two decker, as taken off at Portsmouth
1734
National Maritime Museum

'Monmouth'? (1742). Scale: 1:48. A plan showing the body plan, sheer lines, and the longitudinal half-breadth for 'Monmouth'? (1742), a 1733 Establishment, 70-gun Third Rate two-decker. While the name is in pencil and is of unknown pro
1742
National Maritime Museum

'Saint George' (1740). Scale: 1:96. A plan showing the middle deck, gun deck (lower deck) and the orlop deck for 'Saint George' (1740), a 1733 Establishment 90-gun Second Rate, three decker. The plan shows the deck beams, carlines, led
1742
National Maritime Museum

'Saint George' (1740). Scale: 1:96. A plan showing the round house, quarterdeck and forecastle, and the upper deck for 'Saint George' (1740), a 1733 Establishment 90-gun Second Rate, three decker. The plan shows the deck beams, carline
1742
National Maritime Museum

'Northumberland' (1743). Scale: 1:48. A plan showing the body plan, sheer lines with inboard detail, and longitudinal half-breadth for 'Northumberland' (1743), a 70-gun, Third Rate, two-decker. On the reverse: Scale: 1:48. The upper
1743
National Maritime Museum

'Phoenix' (1743). Scale: 1:48. A plan showing the body plan, sheer lines with inboard detail, and longitudinal half-breadth with upper deck detail for 'Phoenix' (1743), a 1741 Establishment 24-gun Sixth Rate. On the reverse: Scale: 1:
circa September 1743
National Maritime Museum

'Blenheim' (1709). Scale: 1:96. A plan showing the roundhouse, quarterdeck and forecastle, upper deck, middle deck, gun deck (lower deck), and orlop for 'Blenheim' (1709), a 1706 Establishment 90-gun Second Rate, three decker, as hulke
25 April 1743
National Maritime Museum

'Deptford' (proposed 1745). Scale: 1:48. A plan showing the body plan, sheer lines, and longitudinal half-breadth proposed by the Surveyor of the Navy (in green ink), and by the Master Shipwrights of the Royal Dockyards, for 'Deptford'
circa November 1745
National Maritime Museum

'Eagle' (1745). Scale 1:48. A plan showing the body plan, sheer lines with inboard detail, and the longitudinal half-breadth for 'Eagle' (1745), a 1741 Establishment 60-gun Fourth Rate, two-decker.
1745
National Maritime Museum

Unnamed 100-gun First Rate, three-decker (1745). Scale: 1:144. A plan showing an incomplete rigging plan for an unnamed 100-gun First Rate, three-decker (1745). This plan is possibly generic for the 1745 Establishment built 100-gun First Rates.
1745
National Maritime Museum

Unnamed 24-gun Sixth Rate (1745). Scale: 1:144. A plan showing an incomplete rigging plan with figurehead for an unnamed 24-gun Sixth Rate (1745). This plan is possibly generic for the 1745 Establishment built 24-gun Sixth Rates.
1745
National Maritime Museum

Unnamed 50-gun Fourth Rate (1745). Scale: 1:144. A plan showing an incomplete rigging plan with figurehead for an unnamed 50-gun Fourth Rate, two-decker (1745). This plan is possibly generic for the 1745 Establishment built 50-gun Fourth Rates.
1745
National Maritime Museum

Unnamed 80-gun Third Rate, three-decker (1745). Scale: 1:144. A plan showing the rigging plan with figurehead for an unnamed 80-gun Third Rate, three-decker (1745). This plan is possibly generic for the 1745 Establishment built 80-gun Third Rate.
1745
National Maritime Museum

Unnamed 90-gun Second Rate, three-decker (1745). Scale: 1:144. A plan showing an incomplete rigging plan with figurehead for an unnamed 90-gun Second Rate, three-decker (1745). This plan is possibly generic for 1745 Establishment built 90-gun Second Rates
1745
National Maritime Museum

Unnamed proposed 64-gun Third Rate, two-decker (1745). Scale: 1:48. A plan showing the body plan, sheer lines, and longitudial half breadth for an unnamed 64-gun Third Rate, two-decker (1745), proposed by Joshua Allin in 1745. Signed by Joseph Allin [Sur
1745
National Maritime Museum

'Assistance' (1747). Scale: 1:48. A plan showing the body plan with stern board and details, sheer lines with inboard detail, and the longitudinal half-breadth for 'Assistance' (1747), a 1745 Establishment 50-gun Fourth Rate, two-deck
1747
National Maritime Museum

Cambridge (1755). Scale: 1:72. A plan showing the body plan, sheer lines, and the longitudinal half-breadth for Cambridge (1755), an 80-gun Third Rate, three-decker. Note the date is when she was designed and the keel laid at Deptford Dockyard. Reverse s
1750
National Maritime Museum

'Royal Sovereign' (1701), 'Victory' (1738), Unnamed 1745 Establishment 100-gun First Rate three-decker. Scale: 1;48. A plan showing the longitudinal half-breadth, sheer lines below water line and the midship bend comparisons between th
May 1750
National Maritime Museum

'Namur' (1756). Scale: 1:48. A plan showing the body plan, sheer lines, and longitudinal half-breadth for 'Namure' (1756), a 90-gun First Rate three decker. Signed and attested by John Clevland [Secretary to the Admiralty].
12 July 1750
National Maritime Museum

'Dunkirk' (1754). Scale: 1:48. A plan showing the body plan, sheer lines, and the longitudinal half-breadth for 'Dunkirk' (1754), a 60-gun Fourth Rate two-decker. Signed by Joseph Allin [Surveyor of the Navy, 1749-1755].
18 July 1750
National Maritime Museum

'Neptune' (1756). No scale. A plan showing the body plan, sheer lines with some inboard detail and figurehead (in pencil) and the longitudinal half-breadth for 'Neptune' (1756), a 90-gun First Rate, three-decker. Signed by Joseph Al
18 July 1750
National Maritime Museum

'Princess Amelia' (1757). Scale: 1:48. A copy of a plan dated 13 May 1751 showing the body plan, sheer lines, and longitudinal half-breadth for building 'Princess Amelia' (1757), an 80-gun Third Rate, three decker. Note that the plan s
1751-1755
National Maritime Museum

'Cruiser' (1752); 'Speedwell' (1752). Scale: 1:48. A plan showing the body plan with stern board outline, sheer lines with inboard detail, and the longitudinal half-breadth for 'Cruiser' (1752) and 'Speedwell' (1752
1752
National Maritime Museum

'Weymouth' (1752). Scale: 1:48. A plan showing the body plan, sheer lines with inboard detail, and longitudinal half-breadth for 'Weymouth' (1752), a 1745 Establishment 60-gun Fourth Rate, two-decker.
1752
National Maritime Museum

'Montague' (1757). Scale: 1:48. A copy of a plan dated 1750 showing the body plan, sheer lines with timbering of keel and deadwood, and the longitudinal half-breadth for 'Montague' (1757), a modified 1745 Establishment 60-gun Fourth Ra
March 1753
National Maritime Museum

64ft Ketch-rigged Commissioner's Yacht (1754). Scale: 1:32. A plan showing the body plan with stern board outline, sheer lines with inboard detail and figurehead, the longitudinal half-breadth, and the elevations of fore and aft external bulkheads fo
July 1754
National Maritime Museum

'Squirrel' (1755); 'Deal Castle' (1756). Scale: 1:48. A plan showing the body plan, sheer lines, and longitudinal half-breadth for building 'Squirrel' (1755) and 'Deal Castle' (1756), 20-gun Sixth Rates, similar to
13 November 1754
National Maritime Museum

'Royal George' (1756); 'Britannia' (1762). Scale: 1:48. A plan showing the inboard profile for 'Royal George' (1756) and 'Britannia' (1762), both variations of the 1745 Establishment 100-gun First Rate, three decker
1756
National Maritime Museum

'Crown' (1747). Scale: 1:48. A plan showing the inboard profile for the 'Crown' (1747), a 1745 Establishment 44-gun, Fifth Rate, two-decker, as converted into a 24-gun Storeship in 1757.
September 1756 to July 1757
National Maritime Museum

'Crown' (1747). Scale: 1:48. A plan showing the lower deck for 'Crown' (1747), a 1745 Establishment 44-gun, Fifth Rate, two-decker, as converted to a 24-gun Storeship in 1757.
1757
National Maritime Museum

'Crown' (1747). Scale: 1:48. A plan showing the orlop deck with platforms for 'Crown' (1747), a 1745 Establishment 44-gun, Fifth Rate, two-decker, as converted to a 24 gun Storeship in 1757.
1757
National Maritime Museum

'Crown' (1747). Scale: 1:48. A plan showing the quarter deck for 'Crown' (1747), a 1745 Establishment 44-gun, Fifth Rate, two-decker, as converted to a 24-gun Storeship in 1757.
1757
National Maritime Museum

'Crown' (1747). Scale: 1:48. A plan showing the upper deck for 'Crown' (1747), a 1745 Establishment 44-gun, Fifth Rate, two-decker, as converted to a 24-gun Storeship in 1757.
1757
National Maritime Museum

Unnamed single-masted Yacht for the Clerk of the Cheque of Sheerness (circa 1757). Scale: 1:32. A plan showing the body plan, sheer lines with inboard detail (bow missing), deck plan with details (bow missing), and the longitudinal half-breadth (bow missi
May 1757
National Maritime Museum

'Resolution' (1758). Scale: 1:48. A plan showing the forecastle and quarterdeck, as proposed for 'Resolution' (1758), a 74-gun, Third Rate, two-decker.
1758
National Maritime Museum

'Resolution' (1758). Scale: 1:48. A plan showing the orlop deck with fore and aft platforms as proposed for 'Resolution' (1758), a 74-gun, Third Rate, two-decker.
1758
National Maritime Museum

'Resolution' (1758). Scale: 1:48. A plan showing the upper deck as proposed for 'Resolution' (1758), a 74-gun, Third Rate, two-decker.
1758
National Maritime Museum

'Resolution' (1758). Scale: 1:48. A ship plan showing the gun deck (lower deck) as proposed for 'Resolution' (1758), a 74-gun, Third Rate, two-decker.
1758
National Maritime Museum

'Mortar' (1759); 'Carcass' (1759). Scale: 1:48. A plan showing the body plan with stern board outline, sheer lines with inboard detail and scroll figurehead, and longitudinal half-breadth for 'Mortar' (1759), a ketch-rigged B
10 October 1758
National Maritime Museum

'Valiant' (1759). Scale: 1:48. A plan showing the upper deck for 'Valiant' (1759), a 74-gun, Third Rate, two-decker, as built at Chatham Dockyard.
circa August 1759
National Maritime Museum

'London' (1766). Scale: 1:48. A plan showing the inboard profile for 'London' (1766), a 90-gun Second Rate, three decker, building at Chatham Dockyard. Initialled by Thomas Slade [Surveyor of the Navy, 1755-1771]. Reverse: Signed by
24 June 1760
National Maritime Museum

27ft Deal Cutter (1762). Scale: 1:16. A plan showing the body plan, sheer lines with inboard detail, and the longitudinal half-breadth for a seven-oared 27ft Deal Cutter (1762) returned to Woolwich from HMS 'Captain' in December 1762. Regarded a
post January 1763
National Maritime Museum

Unnamed 36ft Chatham Wherry (1758). Scale: 1:24. A plan showing the body plan, sheer lines with inboard details, and the longitudinal half-breadth and deck plan of an unnamed 36ft sinlge-masted Chatham Wherry (1758). Note the lines were taken off in Novem
17 November 1763
National Maritime Museum

'Saint Albans' (1764). Scale: 1:48. A plan showing the upper deck for 'Saint Albans' (1764), a 64-gun, Third Rate, two-decker.
circa 1764
National Maritime Museum

'Prince George' (1772). Scale: 1:48. A plan showing the body plan, sheer lines, and longitudinal half-breadth for 'Prince George' (1772), a 90-gun First Rate, three decker. Signed by Thomas Slade [Surveyor of the Navy, 1755-1771].
11 August 1766
National Maritime Museum

'Raisonnable' (1768) [Alternative spelling: Raisonable]. Scale: 1:48. A ship plan showing the inboard profile for 'Raisonnable' (1768), a 64-gun Third Rate two-decker, building at Chatham Dockyard. Signed by Thomas Slade [Surveyor of
21 January 1767
National Maritime Museum

'Medea' (1778); 'Crescent' (1779). Scale: 1:48. A plan showing the framing profile (disposition) for 'Medea' (1778) and 'Crescent' (1779), both 28-gun Sixth Rate Frigates building at Bristol by Mr Hilhouse. Signe
24 July 1776
National Maritime Museum

'Medea' (1778). Scale: 1:48. A plan showing the inboard profile (incomplete) with figurehead and stern quarter decoration for 'Medea' (1778), a 28-gun Sixth Rate Frigate, as built at Bristol by Mr Hilhouse.
1778
National Maritime Museum

'Cleopatra' (1779). Scale: 1:48. Plan showing the body plan with half stern board outline, sheer lines with inboard detail, and longitudinal half-breadth for building 'Cleopatra' (1778), a 32-gun, Fifth Rate Frigate, at Bristol by Mr H
4 June 1778
National Maritime Museum

'Cleopatra' (1779). Scale: 1:48. A plan showing the inboard profile for 'Cleopatra' (1779), a 32-gun Fifth Rate Frigate. Signed by John Williams [Surveyor of the Navy, 1765-1784].
5 June 1778
National Maritime Museum

Unnamed 93ft three-masted merchant ship (no date). Scale: 1:48. A plan showing the body plan, sheer lines with some inboard detail and scroll figurehead, and longitudinal half-breadth for an unnamed 93ft three-masted merchant ship (no date). Note that th
Mid to late 18th Century
National Maritime Museum

'Serapis' (1782). Scale: 1:48. A plan showing the gun deck (lower deck) for 'Serapis' (1782), a 44-gun Fifth Rate, two-decker. Initialled by Edward Hunt [Surveyor of the Navy, 1778-1784].
10 December 1782
National Maritime Museum

'Serapis' (1782). Scale: 1:48. A plan showing the orlop deck of the 'Serapis' (1782), a 44-gun Fifth Rate, two-decker. Initialled by Edward Hunt [Surveyor of the Navy, 1778-1784].
10 December 1782
National Maritime Museum

'Serapis' (1782). Scale: 1:48. A plan showing the quarterdeck and forecastle for 'Serapis' (1782), a 44-gun Fifth Rate, two-decker. Initialled by Edward Hunt [Surveyor of the Navy, 1778-1784].
10 December 1782
National Maritime Museum

'Serapis' (1782). Scale: 1:48. A plan showing the upper deck for 'Serapis' (1782), a 44-gun Fifth Rate, two-decker. Initialled by Edward Hunt [Surveyor of the Navy, 1778-1784].
10 December 1782
National Maritime Museum

'Nassau' (1785). Scale: 1:48. A plan showing the framing plan (disposition) for 'Nassau' (1785), a 64-gun Third Rate, two-decker, building at Bristol by Mr James Martin Hilhouse. Initialled by John Williams [Surveyor of the Navy, 1765
18 December 1782
National Maritime Museum

'Pilgrim' (1787); and 'Marquess [Marquis] of Worcester' (1789). Scale: 1:48. A ship plan showing the body plan with stern board, the sheer lines with inboard detail and the longitudinal half breadth for 'Pilgrim' (1787) and &
April 1790
National Maritime Museum

Unnamed Dutch barge [?] (1792). Scale: 1:48. A plan showing the measured perspective from the port bow of an unnamed Dutch barge [?] (1792), with her leeboard raised and incomplete rigging. Drawn by James Martin Hilhouse.
1792
National Maritime Museum

28ft Sailing longboat (1795). Scale: 1:24. A plan showing the body plan, sheer lines, and the longitudinal half-breadth of a 28ft Sailing Longboat (1795), built for Mr Fisher.
1795
National Maritime Museum

Unnamed 30ft Shallop (never built). Scale: 1:24. A plan showing the body plan, sheer lines, and longitudinal half-breadth for an Unnamed 30ft Shallop (never built), for the West India trade. Signed by George Hilhouse [Shipbuilder and Merchant], possibl
October 1795
National Maritime Museum

Unspecified merchant ship (fl.1797). Probably 1:48. A plan showing the method of fixing the beams, knees, carlings and lodging knees for the forward half of the main deck of an unspecified merchant ship (fl.1797), as taken off by George Hilhouse in Decemb
1797
National Maritime Museum

'Railleur' (captured 1797). Scale: 1:48. A plan showing the body plan with stern board outline, sheer lines with inboard detail, and longitudinal half-breadth for 'Railleur' (captured 1797), a captured French Privateer, as taken off at
May 1798
National Maritime Museum

'Flying Fish' (1802). Scale: 1:24. A plan (in two parts) showing the body plan, sheer lines, and the longitudinal half-breadth for 'Flying Fish' (1802), a 39ft single-masted Skiff. Signed by Robert Hilhouse [Shipbuilder and Merchant].
circa October 1802
National Maritime Museum

Unnamed 24ft Sprat Boat (1802). Scale: 1:24. Plan showing the body plan, sheer lines, and longitudinal half-breadth for an unnamed 24ft Sprat Boat (1802), built at Bristol by Mr Hilhouse, on 29 October 1802. Mould Loft Number 6. Signed by Robert Hilhouse
1 November 1802
National Maritime Museum

'Albacore' (1804). Scale: 1:48. A plan showing the body plan with half stern board, sheer lines with inboard detail and figurehead, and longitudinal half-breadth for 'Albacore' (1804), a 16-gun Ship Sloop with Quarter deck and Forecast
1803
National Maritime Museum

'Saint Vincent' (1804). Scale: 1:48. A plan showing the half stern board outline, and sheer lines with some inboard detail for the 'Saint Vincent' (1804), a three-decked, three-masted Ship-rigged merchant ship. Annotations and pencil a
1803
National Maritime Museum

'John' (1803). Scale: 1:24. A plan showing the body plan, sheer lines with inboard detail, and the longitudinal half-breadth with deck details for 'John' (1803), a 43ft long two-masted merchant Schooner.
June 1803
National Maritime Museum

'Amphitrite' (captured 1804), later 'Blanche' (renamed 1805). Scale: 1:72? (graduated bar scale). A plan showing the body plan, sheer lines with inboard detail and figurehead, and longitudinal half-breadth for 'Amphitrite' (1
Circa 1797
National Maritime Museum

16ft Moses Punt (1806). Scale: 1:24. A plan showing the body plan, sheer lines with inboard detail, and longitudinal half-breadth for a 16ft four-oard Moses type punt (1806). Signed by George Hilhouse [Shipbuilder and Merchant].
November 1806
National Maritime Museum

20ft Gig (1806). Scale: 1:24. A plan showing two body plans, a sheer lines with inboard detail, and the longitudinal half-breadth with half deck plan for a six-oared 20ft Gig (1806), built for Captain Walker. Signed by George Hilhouse [Shipbuilder and
November 1806
National Maritime Museum

20ft Longboat (1806). Scale: 1:24. A plan showing the body plan, sheer lines and the longitudinal half-breadth of a 20ft Longboat [Longboat Number 12] (1806) to carry two hogsheads or four puncheons. See HIL0099 for an office copy of this plan.
November 1806
National Maritime Museum

24ft Pinnace (1807). Scale 1:24. A plan showing the body plan, sheer lines, and the longitudinal half-breadth for a 24ft Pinnace (1807). Mould Loft Number 18? Signed by George Hilhouse [Shipbuilder and Merchant].
August 1807
National Maritime Museum

25ft Gig (1806). Scale: 1:24. A plan showing two body plans, a sheer lines with inboard detail, longitudinal half-breadth, and the longitudinal half deck plan for a six-oared 25ft Gig (1806), built for Captain Baker, October 1806. Signed by George Hilh
April 1807
National Maritime Museum

15ft Yawl (1807). Scale: 1:24. A ship plan showing two body plans, a sheer lines with inboard detail, and the longitudinal half-breadth with half deck plan for an eight-oared 15ft Yawl (1807). The second body plan is described as the "improved body&q
August 1807
National Maritime Museum

22ft Cutter (1807) for HM Customs. Scale: 1:24. A plan showing the body plan, sheer lines, and longitudinal half-breadth for a 22ft Cutter (1807), designed for HM Customs.
circa August 1807
National Maritime Museum

23ft to 28ft Longboat (1807). Scale: 1:24. A plan showing the body plan, sheer lines, and the longitudinal half-breadth for a 23ft to 28ft Longboat (1807) to carry 99 Hogsheads. Note that the plan shows the vessel as 23ft long. Signed by George Hilhouse
September 1807
National Maritime Museum

22ft Cutter (1808). Scale: 1:24. A plan showing the body plan, sheer lines with inboard detail, the midship section, and the longitudinal half-breadth for a 22ft five-oared clinker-built Cutter (1808). Mould Loft Number 16. Signed by George Hilhouse [Shi
January 1808
National Maritime Museum

'Charlotte Skiff' (1808). Scale: 1:24. A plan showing the body plan, sheer lines with inboard detail, and deck plan for 'Charlotte Skiff' (1808), a cutter built for John Berry. Signed by George Hilhouse [Shipbuilder and Merchant], p
March 1808
National Maritime Museum

34ft Ceremonial Barge for Bristol Dock Company (1809). Scale: 1:24. A plan showing the body plan with half-stern board detail, sheer lines with inboard detail, and longitudinal half-breadth with half plan for a 34ft ceremonial barge for the Bristol Dock C
May 1809
National Maritime Museum

18ft Gig (1809). Scale: 1:24. A plan showing the body plan, sheer lines, half breadth, and longitudinal half breadth for a four-oared 18ft Gig (1809), built for J. M. H. [James Martin Hilhouse]. Mould Loft Number 23.
August 1809
National Maritime Museum

Unnamed 116ft Steam Packet (circa 1823). Scale: 1:48. A plan showing the body plan with paddle box bracing, sheer lines with paddle box bracing, and the longitudinal half-breadth with paddle box bracing, and detail of the iron bracing for an unnamed 116ft
9 January 1823
National Maritime Museum

'Elizabeth' (1832). Scale: 1:48. A plan showing the inboard profile for 'Elizabeth' (1832), a 114ft three-masted ship-rigged merchant ship. Mould Loft Number 79.
1832
National Maritime Museum

'Trusty' (1834). 1:48. A ship plan showing the inboard profile for 'Trusty' (1834), a 111ft three-masted ship-rigged merchant ship. Mould Loft Number 82. Reverse: An incomplete sheer lines for an unknown merchant ship.
circa 1834
National Maritime Museum

Unnamed 81ft vessel (no date, possibly 1825). Scale: 1:48. A plan showing the body plan, sheer lines, and the longitudinal half-breadth for an unnamed 81ft vessel (no date, possibly 1825). Note: pencil annotation has no known provenance and the name is u
Possibly 1825
National Maritime Museum

'Ruby' (1838). Scale: 1:48. A plan showing the inboard profile for 'Ruby' (1838), a 109ft three-masted ship-rigged merchant ship. Mould Loft Number 89. The Lloyd's Survey Report (BRS278) confirms the dimensions and tonnage. The
January 1838
National Maritime Museum

'Elvira' (1835). Scale: 1:48. A plan showing the inboard profile for 'Elvira' (1835), a 99ft three-masted barque-rigged merchant ship. Mould Loft Number 86 (85 crossed out).
circa 1835
National Maritime Museum

Long boat No 1 (1831). Scale: 1:24. A plan showing the body plan with modifications, sheer lines, and longitudinal half-breadth for the 25ft Longboat No 1 (circa 1831). The identity of this plan is uncertain. The pencil annotations are undated with an un
circa 1831
National Maritime Museum

paddle steamer (circa 1831). Scale 1:32. A plan showing an elevation and sectional view of the close stowing paddle wheel. The drawing is accompanied by an explanatory note to the effect that the process of removing the paddle blades would be too time-con
Dated: 1831
National Maritime Museum

'Victoria' (1831). Scale: 1:48. A plan showing the inboard profile, and accommodation plan for Victoria (1831), 109ft three-masted ship-rigged merchant ship. Mould Loft Number 78. Attached to the front of this plan is a note in ink entitled �
circa 1831
National Maritime Museum

Unnamed 122ft three-masted merchant ship (no date). Scale: 1:48. A plan showing the body plan, sheer lines, and longitudinal half-breadth for unnamed 122ft three-masted merchant ship (no date). A pencil note records she was not built.
1838 or later
National Maritime Museum

Notebook containing preparation drawings of the construction and fitting for 'Persia' (1855).. A 72 page notebook containing drawings and diagrams relating to the construction and fitting for 'Persia' (1855) in preparation for the draw
1857 to 1860
National Maritime Museum

'Medal awarded to David Kirkaldy, Glasgow. For a correct and beautifully executed drawing of the Persia.'. A bronze-coloured embossed medal (seal) mounted on stiffened paper awarded to David Kirkaldy for the plan of 'Persia' (1855).
1860
National Maritime Museum

'Persia' (1855). Scale: 1:96. Plan showing the outboard longitudinal profile, sections with inboard detail through Stations A, B, C, D (through the paddle wheels), E, F, and G, and a detailed inboard longitudinal profile for 'Persia'
30 January 1857 to 11 November 1860
National Maritime Museum

Thermopylae (1868). Scale 1:24. Drawing showing the midships section for Thermopylae (1868), a clipper.
17 July 1867
National Maritime Museum

Half midship section plan of the clipper Cutty Sark (1869). Scale: 1:32. An original plan showing the half-midship section for the clipper Cutty Sark (1869). The detailed plan illustrates the composite construction of the vessel (wooden planking on iron f
1869
National Maritime Museum

Princess Elizabeth (1927). Scale 1:48. Plan showing the 'as fitted' General Arrangement of the Main and Lower Decks for the excersion paddle steamer Princess Elizabeth (1927). Drawing no. 2161; no archive? number. See also DAS0141 to DAS0209
Circa 1927
National Maritime Museum

Oriental (1849). Scale 1:48. Drawing showing the sheer lines, body plan and longitudinal half breadth for Oriental (1849), an American clipper.
1928
National Maritime Museum

Fidelity (1904). Scale 1:24. A plan showing the inboard profile, midships section and deck of the Fidelity (1904), a Zulu. The plan is signed 'P J Oke, Plymouth' and is dated June 1936.
Dated: June 1936
National Maritime Museum
