Belfast (1938). Scale 1:96. A plan showing the inboard profile of the Edinburgh class light cruiser HMS Belfast (1938), illustrating the planned 1956-1959 extended refit. A note on the plan states that it is correct to January 1959.
April 1956
National Maritime Museum

Belfast (1938). Scale 1:96. A plan showing the platform in hold [no. 4 deck] and hold [no. 5 deck] of the Edinburgh class light cruiser HMS Belfast (1938), illustrating the planned 1956-1959 extended refit. A note on the plan states that it is correct to
April 1956
National Maritime Museum

Belfast (1938). Scale 1:96. A plan showing the upper [no. 2] and lower [no. 3] decks of the Edinburgh class light cruiser HMS Belfast (1938), illustrating the planned 1956-1959 extended refit. A note on the plan states that it is correct to January 1959.
April 1959
National Maritime Museum

Belfast (1938). Scale 1:96. A plan showing the hull sections at stations 13, 30, 46, 72, 96, 126, 145, 172, 198, 218, 232, 251, and the aft peak of the Edinburgh class light cruiser HMS Belfast (1938), illustrating the results of her 1956-1959 extended re
October 1959
National Maritime Museum

Belfast (1938). Scale 1:96. A plan showing the inboard profile of the Edinburgh class light cruiser HMS Belfast (1938), illustrating the results of her 1956-1959 extended refit.
October 1959
National Maritime Museum

Belfast (1938). Scale 1:96. A plan showing the platforms in hold [no. 4 deck] and hold [no. 5 deck] of the Edinburgh class light cruiser HMS Belfast (1938), illustrating the results of her 1956-1959 extended refit.
October 1959
National Maritime Museum

Belfast (1938). Scale 1:96. A plan showing the upper bridge [04 level], compass flat [03 level], lower bridge [02 level], superstructure [01 level] and forecastle [no. 1 deck] of the Edinburgh class light cruiser HMS Belfast (1938), illustrating the resul
October 1959
National Maritime Museum

Belfast (1938). Scale 1:96. A plan showing the upper [no. 2] and lower [no. 3] decks of the Edinburgh class light cruiser HMS Belfast (1938), illustrating the results of her 1956-1959 extended refit.
October 1959
National Maritime Museum
