18 ft Cutter. Scale: 1:48. Plan showing the sail plan for an 18 ft Cutter. Annotations in 1886, listing where copies were sent to.
Dated: February 1886
National Maritime Museum

Colossus (1882). Scale 1:48. A plan showing the inboard profile of the Colossus class turret ship HMS Colossus (1882). The plan has been signed by Henry E. Deadman [Chief Constructor, Portsmouth Dockyard]. Alterations in green ink denote work carried out
July 1886
National Maritime Museum

Colossus (1882). Scale 1:48. A plan showing the main deck of the Colossus class turret ship HMS Colossus (1882). Alterations carried out by Thames Iron Works in 1903 are marked in green on the drawing. The plan bears the signature of H E Deadman [Chief C
July 1886
National Maritime Museum

Colossus (1882). Scale 1:48. A plan showing the upper deck and seamen's head of the Colossus class turret ship HMS Colossus (1882). The plan has been signed by Henry E. Deadman [Chief Constructor, Portsmouth Dockyard]. Alterations in green ink denot
July 1886
National Maritime Museum

Colossus (1882). Scale 1:48. A plan showing the upper superstructure of the Colossus class turret ship HMS Colossus (1882). The plan has been signed by Henry E. Deadman [Chief Constructor, Portsmouth Dockyard]. Alterations in green ink denote work carrie
July 1886
National Maritime Museum

Colossus (1882). Scale 1:48. A plan with accompanying table of torpedo room capacity showing the lower deck of the Colossus class turret ship HMS Colossus (1882). The plan has been signed by Henry E. Deadman [Chief Constructor, Portsmouth Dockyard]. Alte
July 1886
National Maritime Museum

Colossus (1882). Scale 1:48. A plan with accompanying tables of magazine capacity showing the hold and hull sections at stations 18, 30, 42, 54, 60, 90, 104, 114, 126, 134, 136 and 144 of the Colossus class turret ship HMS Colossus (1882). The plan has be
July 1886
National Maritime Museum

16 ft Cutter. Scale: 1:48. Plan showing the sail plan for a 16 ft Cutter. Annotations in 1886, listing where copies sent to.
Dated: February 1886
National Maritime Museum

20 ft Cutter. Scale: 1:48. Plan showing the sail plan for a 20 ft Cutter. Annotations in 1886, listing where copies were sent to.
Dated: February 1886
National Maritime Museum

23 ft Cutter. Scale: 1:48. Plan showing the sail plan for a 23 ft Cutter. Annotations in 1886, listing where copies were sent to.
Dated: February 1886
National Maritime Museum

25 ft Cutter. Scale: 1:48. Plan showing the sail plan for a 25 ft Cutter. Annotations in 1886, listing where copies were sent to.
Dated: February 1886
National Maritime Museum

27 ft Cutter. Scale: 1:48. Plan showing the sail plan for a 27 ft Cutter. Annotated in 1886, listing where copies were sent to.
Dated: February 1886
National Maritime Museum

28 ft Cutter. Scale: 1:48. Plan showing the sail plan for a 28 ft Cutter. Annotated in 1886, listing where copies were sent to.
Dated: February 1886
National Maritime Museum

30 ft Cutter. Scale: 1:48. Plan showing the sail plan for a 30 ft Cutter. Annotated in 1886, listing where copies were sent to.
Dated: February 1886
National Maritime Museum

32 ft Cutter. Scale: 1:48. Plan showing the sail plan for a 32 ft Cutter. Annotated in 1886, listing where copies were sent to.
Dated: February 1886
National Maritime Museum

34 ft Cutter. Scale: 1:48. Lithograph showing the sail plan for a 34 ft Cutter. Annotated in 1886, listing where copies were sent to.
Dated: February 1886
National Maritime Museum

Truck for transporting Gigs and Whalers. Scale: 1:12. Plan showing a front and side elevation, and plan of a truck for transporting Gigs and Whalers, and to be modified for Cutters of 25ft or less in length. Signed J. B. Huddy [Chief Constructor, Devo
9 April 1886
National Maritime Museum

Truck for transporting Gigs and Whalers. Scale: 1:12. Plan showing a front and side elevation, and plan of a truck for transporting Gigs and Whalers, and to be modified for Cutters of 25ft or less in length. Signed J. B. Huddy [Chief Constructor, Devo
9 April 1886
National Maritime Museum

Truck for transporting Gigs and Whalers. Scale: 1:12. Plan showing a front and side elevation, and plan of a truck for transporting Gigs and Whalers, and to be modified for Cutters of 25ft or less in length. Signed J. B. Huddy [Chief Constructor, Devo
9 April 1886
National Maritime Museum

Colossus (1882). Scale 1:48. A plan with accompanying table of magazine capacity showing the platform deck of the Colossus class turret ship HMS Colossus (1882). The plan has been signed by Henry E. Deadman [Chief Constructor, Portsmouth Dockyard]. Alter
July 1886
