. gun
1869
National Maritime Museum

. lines & profile
1869
National Maritime Museum

. mast, telescopic
1869
National Maritime Museum

. sail
1869
National Maritime Museum

Magdala (1869). Scale: 1:24. Plan showing the body plan, sheer lines, and longitudinal half-breadth for Magdala (1868), an 8-oared 23 ft Cutter.
Dated: 12 January 1869
National Maritime Museum

Sail plans for 23ft Cutter, 25ft Cutter, and 14ft Dinghy. No scale. Plan showing the sail plans for 23ft Cutters, 25ft Cutters, and 14ft Dinghies.
1869
National Maritime Museum

. Lower deck plan
5 Feb 1869
National Maritime Museum

. profile
5 Feb 1869
National Maritime Museum

23 ft Cutter. Scale: 1:16. Plan showing the body plan, sheer lines with inboard detail, longitudinal half-breadth for a 23 ft Cutter, later used for a Jolly Boat. Signed W. B, Robinson [Chief Constructor, Portsmouth Dockyard, 1869-?]. The plan seems to
Originally dated: 11 September 1869
National Maritime Museum

32ft Galley (1869). Scale: 1:16. Plan showing the body plan, sheer lines with some detail, and longitudinal half-breadth for a 32ft 14 oared Galley. The plan was later passed to Devonport Dockyard in 1875. Signed by W.B. Robinson [Master Shipwright (late
11 September 1869
National Maritime Museum

32ft Galley or Gig (1869). Scale: 1:16. Plan showing the body plan, sheer lines with some inboard detail, and longitudinal half-breadth for a 32ft 14-oared Galley or Gig. Signed by William B. Robinson [Master Shipwright (later Chief Constructor), Portsmo
11 September 1869
National Maritime Museum
