. lines
1868
National Maritime Museum

. lines & profile
1868
National Maritime Museum

. lines & profile
1868
National Maritime Museum

. profile
1868
National Maritime Museum

. steering apparatus
1868
National Maritime Museum

27ft Steam Cutter (1868). Scale: 1:16. Plan showing the body plan, rig, inboard profile, and deck plan for a 27ft Steam Cutter built at Bermuda for Gannet (1857), a 9-gun wooden screw sloop. The cutter was rigged as a two-masted standing lug-rigged cutte
Circa July 1868
National Maritime Museum

27ft Steam Life Boat Cutter No.5. Scale: 1:24. Plan showing the body plan, sheer lines, and longitudinal half-breadth for a 27ft Steam Life Boat Cutter No.5. Signed by Ebenezer Wood [Assistant Master Shipwright, Portsmouth Dockyard, November 1862-1870].
31 October 1868
National Maritime Museum

29ft Steam Pinnace No.6. Scale: 1:24. Plan showing the body plan, sheer lines, and longitudinal half-breadth, for a 29ft Steam Pinnace No.6. Signed by Henry Cradock [Master Shipwright, Portsmouth Dockyard, 1862-1869].
21 May 1868
National Maritime Museum

27ft Steam Life Boat Cutter No.4. Scale: 1:24. Plan showing the body plan, sheer lines, longitudinal half-breadth for a 27ft Steam Life Boat Cutter No.4. Signed by Henry Cradock [Master Shipwright, Portmouth Dockyard, 1862-1869].
11 March 1868 (29 February 1868 crossed out)
National Maritime Museum

28ft Steam Life Boat Cutter No.3. Scale: 1:24. Plan showing the body plan, sheer lines with some inboard detail, longitudinal half-breadth and half-deck plan, for a 28ft Steam Life Boat Cutter No.3. Signed by Henry Cradock [Master Shipwright, Portsmouth
11 March 1868 (29 February 1868 crossed out)
National Maritime Museum

38 ft Pinnace. Scale: 1:24. Plan showing the body plan, sheer lines with some inboard detail, and longitudinal half-breadth for a 16 oared, 38 ft Pinnace for screw ships. Copies sent to the Royal Dockyards. Includes annotations for 1880.
Dated: 17 January 1853
National Maritime Museum

Achilles (1861). sail
Aug 1868
National Maritime Museum
