Design for a 205ft, 90-gun Seond Rate, three-decker (no date).. Scale: 1:48. A plan showing the body plan, sternboard outline, sheer lines, and longitudinal half-breadth for a 205ft, 90-gun Second Rate, three-decker. It was recorded that she was 200 tons
No date, possibly 1850
National Maritime Museum

32 ft Pinnace. Scale: 1:24. Plan showing the plan and profile for a 12 pounder brass Howitzer and slide; and the body plan, profile with some inboard detail, and deck plan for a 32 ft Pinnace and/or 32 ft Barge as fitted with a 12 pounder Howitzer in th
Dated: 22 March 1850
National Maritime Museum

Phaeton (1848). Scale: 1:48. Plan showing the hold with sections through stations at A, B, C, D illustrating the barrel stowage, magazine, water tanks and stores for Phaeton (1848), a 50-gun large Frigate. The ship was built at Deptford but completed at
8 April 1850
National Maritime Museum

Phaeton (1848). Scale: 1:48. Plan showing the main deck illustrating the tiller ropes, shot layout and fittings for Phaeton (1848), a 50-gun large Frigate. The ship was built at Deptford but completed at Sheerness Dockyard. Signed by Sameul Read [Mast
8 April 1850
National Maritime Museum

Phaeton (1848). Scale: 1:48. Plan showing the orlop deck illustrating the details of the store rooms for Phaeton (1848), a 50-gun large Frigate. The ship was built at Deptford but completed at Sheerness Dockyard. Signed by Samuel Read [Master Shipwrigh
8 April 1850
National Maritime Museum

Phaeton (1848). Scale: 1:48. Plan showing the inboard profile with details for Phaeton (1848), a 50-gun large Frigate. The ship was built at Deptford but completed at Sheerness Dockyard. Signed by Samuel Read [Master Shipwright, Sheerness Dockyard 1848
25 June 1850
National Maritime Museum

Emerald (1856). Scale: 1:48. Plan showing the framing profile (disposition) illustrating the use of winter felled and summer felled timbers for Emerald (1856), a 60-gun Fifth Rate Large Frigate, prior to being re-ordered in 1854 as a screw frigate and le
17 July 1850
