. boat
1849
National Maritime Museum

. channels
1849
National Maritime Museum

. deck, quarter & forecastle
1849
National Maritime Museum

. Inboard profile plan
1849
National Maritime Museum

. Lower deck plan
1849
National Maritime Museum

. Main deck plan
1849
National Maritime Museum

. platform
1849
National Maritime Museum

. profile
1849
National Maritime Museum

. store rooms
1849
National Maritime Museum

Arrogant (1848). Scale: 1:12. Plan showing a part section illustrating the plug for the waste water pipe, and a front and plan view of the plug, as fitted to Arrogant (1848), a 46-gun First Class Screw Frigate.
Circa April 1849
National Maritime Museum

Immortalite (1859); Melpmene (1857). Scale: 1:48. Plan showing the body plans with sternboard outline, sheer lines, and longitudinal half-breadth proposed (and approved) for Immortalite (1859) and Melpomene (1857), both 60-gun Large Frigates, which were
28 May 1849
National Maritime Museum

Steering Wheel (1849). Various scales. Plan showing the side and front elevation of a steering wheel, and detail elevations of the bolts and rings for a steeering wheel, illustrating how they are built at Portsmouth Dockyard. Signed John Fincham [Master
7 April 1849
National Maritime Museum

Leander (1848). Scale: 1:48. Plan showing a plan and starboard side elevation of the head to be fitted to Leander (1848), a large 50-gun Frigate. The plan illustrates the arrangement for directing the effluent from the heads/toilets in the bows. A copy
14 October 1849
National Maritime Museum

Leander (1848). Scale: 1:48. Plan showing the fore, middle and after platform decks (orlop) as fitted on Leander (1848), a large 50-gun Frigate. The plan illustrates the various store rooms including the Spirit Room, Boatswain's Store and Carpenter
12 December 1849
National Maritime Museum

Leander (1848). Scale: 1:48. Plan showing the inboard profile and fittings as fitted on Leander (1848), a large 50-gun Frigate. The plan includes faint pencil annotations relating to her 1860-1 conversion to a screw frigate. Signed by John Fincham [Mas
12 December 1849
National Maritime Museum

Leander (1848). Scale: 1:48. Plan showing the lower deck with cabin layout and shor rack detail as fitted on Leander (1848), a large 50-gun Frigate. Signed by John Fincham [Master Shipwright, Portsmouth Dockyard, 1844-1852] Signed by D Warders [unknown
12 December 1849
National Maritime Museum

Leander (1848). Scale: 1:48. Plan showing the plan and sections for the hold as fitted on Leander (1848), a large 50-gun Frigate. The plan includes tables of water stowage, ballast stowage, shell stowage, and provisions details. Signed by John Fincham
12 December 1849
National Maritime Museum

Leander (1848). Scale: 1:48. Plan showing the quarterdeck and forecastle as fitted on Leander (1848), a large 50-gun Frigate. The plan includes details of the shot racks, heads gratings and hammock stowage. Signed by John Fincham [Master Shipwright, Po
12 December 1849
National Maritime Museum

Leander (1849). Scale: 1:48. Plan showing the main (upper) deck as fitted for Leander (1848), a large 50-gun Frigate. The plan includes some of the fitting details such as Mr J. Brown's cable stopper. Signed by John Fincham [Master Shipwright, Por
12 December 1849
