'Pincher' (1827). Scale: 1:48. Plan showing the body plan with half stern board outline, sheer lines with inboard detail, and longitudinal half-breadth for 'Pincher' (1827), a 3-gun Schooner, as taken off at Chatham Dockyard. Signed b
September 1837
National Maritime Museum

'Pincher' (1827). Scale: 1:48. Plan showing the upper deck, and lower deck for 'Pincher' (1827), a 3-gun Schooner, as taken off at Chatham Dockyard. Note the pencil outline of a swivel-mounted gun on the centre line of the upper deck.
September 1837
National Maritime Museum

'Pincher' (1827). Scale: 1:96. Plan showing the sail plan for 'Pincher' (1827), a 3-gun Schooner.
7 October 1837
National Maritime Museum

. deck
1837
National Maritime Museum

. deck, orlop
1837
National Maritime Museum

. deck, quarter & forecastle
1837
National Maritime Museum

. Inboard profile plan
1837
National Maritime Museum

. lines
1837
National Maritime Museum

. lines & profile
1837
National Maritime Museum

. Lower deck plan
1837
National Maritime Museum

. sail
1837
National Maritime Museum

. section, midship
1837
National Maritime Museum

. Upper deck plan
1837
National Maritime Museum

Asia (1824). Scale: 1:48. Plan showing the sections and plan illustrating the storage of the tanks, barrels, and ballast for Asia (1824), an 84-gun Second Rate, two-decker. Signed by John Fincham [Master Shipwright, Sheerness Dockyard, 1835-1839].
20 January 1837
National Maritime Museum

Nymph (1812). Scale: 1:48. Plan showing the upper deck for Nymph (1812), a 38-gun Fifth Rate, Frigate, as proposed to be fitted for an Ordinary Guardship without a poop deck. Reverse: Scale: 1:48. Plan showing the upper deck for Nymph (1812), a 38-gun
January 1837
National Maritime Museum

Nymphe (1812). Scale: 1:48. Plan showing the upper deck for Nymph (1812), a 38-gun Fifth Rate, Frigate, as proposed to be fitted for an Ordinary Guardship with a poop deck. This plan is the neat version of the sketch on ZAZ2550. Signed by William Stone
25 January 1837
National Maritime Museum

Nymphe (1812). Scale: 1:48. Plan showing the upper deck for Nymph (1812), a 38-gun Fifth Rate, Frigate, as proposed to be fitted for an Ordinary Guardship without a poop deck. The plan includes alterations to the accommodation in pencil. This plan is th
25 January 1837
National Maritime Museum

Scout (1832). Scale: 1:48. Plan showing the upper deck as fitted for Scout (1832), an 18-gun Sloop. Signed by John Fincham [Master Shipwright, 1835-1839] and T Sturdee [Unknown].
2 February 1837
National Maritime Museum

Squirrel (1853); Liberty (1850). Scale: 1:24. Plan showing the midship section with midship framing elevation for Squirrel (1853) and Liberty (1850), both 16-gun Second class Brigs building at Pembroke Dockyard.
3 May 1837
National Maritime Museum

Squirrel (1853); Liberty (1850). Scale: 1:48. Plan showing the body plan with half stern board outline, sheer lines and longitudinal half-breadth for Squirrel (1853) and Liberty (1850), both 16-gun Second class Brigs building at Pembroke Dockyard. The l
3 March 1837
National Maritime Museum

Squirrel (1853); Liberty (1850). Scale: 1:48. Plan showing the lower deck with a faint pencil section for Squirrel (1853) and Liberty (1850), both 16-gun Second class Brigs building at Pembroke Dockyard.
Circa 1837
National Maritime Museum

Terror (1813). Scale: 1:48. Plan showing the inboard detail for Terror (1813), a Bomb Vessel as converted for Arctic Service under Captain George Back in 1836. The plan is subsequently dated December 1837 after it was used at Chatham to assist with the
March 1836
National Maritime Museum

Terror (1813). Scale: 1:48. Plan showing the lower deck illustrating the cabin arrangements and some fitted furniture for Terror (1813), a Bomb Vessel as convered for Arctic Service under Captain George Back in 1836. Signed by William Stone [Master Ship
December 1837
National Maritime Museum

Terror (1813). Scale: 1:48. Plan showing the upper deck with some deck fittings for Terror (1813), a Bomb Vessel converted for Arctic Service under Captain George Back in 1836. Signed by William Stone [Master Shipwright, Chatham Dockyard, 1830-1839].
December 1837
National Maritime Museum

The method of clinching a chain cable by using a slip-hook, for all warshps. Scale: 1:24. Plan showing the method of clinching (fastening) a chain cable using a slip hook, for all warships. It seems this plan was drawn at Chatham in January 1837, but mo
January 1837
National Maritime Museum

Cable compressor. No scale. A plan showing the cut away elevation and plan view from below deck of the upper chain compressor approved by the Board of Admiralty as the upper compressor for all His Majesty's Ships, but later not to be adopted until fu
January 1837
National Maritime Museum

Violet (1835). Scale: 1:48. Plan showing the body plan, sheer lines with inboard detail (and leeboards), and longitudinal half-breadth for Violet (1835), a Tender to HMS Survey Sloop Fairy (1826), as taken off at Sheerness Dockyard by Admiralty Order, 19
20 January 1837
National Maritime Museum

Tank Vessel No. 1 (1837). Scale: 1:96. A plan showing the sail profile with mast and spar dimensions, and sail area, for Tank Vessel No. 1 (1837), a two-masted Water Carrier built for service in Malta.
11 February 1837
National Maritime Museum

'Hawke' (1820). Scale: 1:48. Plan showing the gun deck (lower deck) for 'Hawke' (1820), a 74-gun Third Rate, two-decker, as fitted in 1837. The plan also includes alterations suggested in a letter dated 25 March 1837. Signed William S
17 March 1837
National Maritime Museum

'Hawke' (1820). Scale: 1:48. Plan showing the inboard profile to waterline for 'Hawke' (1820), a 74-gun Third Rate, two-decker, as fitted in 1837. The plan also includes alterations suggested in a letter dated 25 March 1837. Signed Wi
17 March 1837
National Maritime Museum

'Hawke' (1820). Scale: 1:48. Plan showing the orlop deck with fore and aft platforms for 'Hawke' (1820), a 74-gun Third Rate, two-decker, as fitted in 1837. The plan also includes alterations suggested in a letter dated 25 March 1837.
17 March 1837
National Maritime Museum

'Hawke' (1820). Scale: 1:48. Plan showing the roundhouse, quarterdeck, and forecastle for 'Hawke' (1820), a 74-gun Third Rate, two-decker, as fitted in 1837. The plan also includes alterations suggested in a letter dated 25 March 1837
17 March 1837
National Maritime Museum

'Hawke' (1820). Scale: 1:48. Plan showing the upper deck for 'Hawke' (1820), a 74-gun Third Rate, two-decker, as fitted in 1837. The plan also includes alterations suggested in a letter dated 25 March 1837. Signed William Stone [Maste
17 March 1837
National Maritime Museum

Albatross (1842); Bittern (1840); Elk (1847); Heron (1847); 16 gun First Class Brigs. Scale: 1:48. Plan showing the body plan with half stern board outline, sheer lines with some inboard detail and framing detail, and longitudinal half-breadth for 16 gun
18 March 1837
National Maritime Museum

Mercury (1837). Scale: 1:32. Plan showing the inboard profile for Mercury (1837), as fitted as a single-masted Tender. Signed by William Stone [Master Shipwright, Chatham Dockyard, 1830-1839].
18 March 1837
National Maritime Museum

Mercury (1837). Scale: 1:32. Plan showing the upper deck, and the lower deck with elevations, for Mercury (1837, as fitted as a single-masted Tender. Signed by William Stone [Master Shipwright, Chatham Dockyard, 1830-1839]
18 March 1837
National Maritime Museum

Sparrow (1828). Scale: 1:48. Plan showing the inboard profile for Sparrow (1828), a single-masted 10-gun Cutter, as altered and fitted to a two-masted Ketch for service in the Falkland Islands. Signed by Richard Blake [Master Shipwright, Portsmouth Dock
17 May 1837
National Maritime Museum

Sparrow (1828). Scale: 1:48. Plan showing the upper deck, and lower deck for Sparrow (1828), a single-masted 10-gun Cutter, as altered and fitted to a two-masted Ketch for service in the Falkland Islands. Signed by Richard Blake [Master Shipwright, Port
17 May 1837
National Maritime Museum

Spartan (1841), Creole (1845), Amethyst (1844), Niobe (1849). Scale 1:48. Plan showing the body plan with half stern board and frame outline, sheer lines with midship framing, and longitudinal half breadth for Spartan (1841) and Creole (1845), and later w
12th July 1837
National Maritime Museum

Spartan (1841), Creole (1845), Amethyst (1844), Niobe (1849). Scale 1:48. Plan showing the midship section for Spartan (1841) and Creole (1845), and later for Amethyst (1844) and Niobe (1849), all 28-gun Sixth Rate ships. Spartan (1841) was was later del
12th July 1837
National Maritime Museum

Tank Vessel No. 1 (1837). Scale: 1:48. A plan showing the inboard profile, upper deck, and platforms and flats, for Tank Vessel No. 1 (1837), a two-masted Water Carrier built for service in Malta. Signed by William Stone [Master Shipwright, Chatham Do
26 July 1837
National Maritime Museum

Griffon (1832), Forester (1832), Charybdis (1831), Buzzard (1834), Lynx (1833), and Termagant (1838).. Scale possibly: 1:96. Plan showing the 'hermaphrodite' rig (Brigantine) for Griffon (1832) as fitted, and Forester (1832), both 10-gun Brigan
Circa October 1837
National Maritime Museum

Griffon (1832), Charybdis (1831), Brisk (1819), Lynx (1833), Termagant (1838), Forester (1832). Scale: 1:96. Plans showing the sail plan for Griffon (1832), Charybdis (1831), Brisk (1819), Lynx (1833), Termagant (1838), all 10-gun Brigantines, and in red
9 October 1837
National Maritime Museum

Terror (1813). Scale: 1:48. Plan showing the orlop and hold with platforms for Terror (1813), a Bomb vessel, as converted to an exploration vessel for the Arctic (under Captain George Back). The plan includes elevations of the sloproom racks and the stor
December 1837
National Maritime Museum

Racehorse (1830). Scale: 1:48. Plan showing the fore part of the upper deck for Racehorse (1830), an 18-gun flush-decked Ship Sloop. The plan illustrates the proposed alterations of the fore hatchway, grating &c to allow the main topmast to be stowe
11 December 1837
National Maritime Museum
