'Barham' (1811). Scale: 1:48. Plan showing the inboard profile with some external detail for 'Barham' (1811), a 74-gun Third Rate, two-decker, as cut down to a 50-gun Fourth Rate Frigate at Woolwich Dockyard. The plan includes altera
19 January 1827
National Maritime Museum

'Barham' (1811). Scale: 1:48. Plan showing the orlop platform with fore & aft plaforms for 'Barham' (1811), a 74-gun Third Rate, two-decker, as cut down to a 50-gun Fourth Rate Frigate at Woolwich Dockyard. Signed by Oliver Lang
19 January 1827
National Maritime Museum

'Barham' (1811). Scale: 1:48. Plan showing the upper deck for 'Barham' (1811), a 74-gun Third Rate, two-decker, as cut down to a 50-gun Fourth Rate Frigate at Woolwich Dockyard. This deck used to the lower deck when she was a 74-gun
19 January 1827
National Maritime Museum

'Caledonia' (1808); 'Saint George' (1840); 'Neptune' (1832). Scale: 1:48. Plan showing the inboard profile for 'Saint George' (1840) building at Plymouth Dockyard, and for the 'Caledonia' (1808), repairing
20 June 1827
National Maritime Museum

'Rodney' (1833). Scale 1:48. Plan showing the half stern framing for 'Rodney' (1833), a 92-gun Second Rate, two-decker. The plan illustrates the timbers required for the circular stern. Initialled by Robert Seppings [Surveyor of the N
22 December 1827
National Maritime Museum

. deck
1827
National Maritime Museum

. Inboard profile plan
1827
National Maritime Museum

. lines
1827
National Maritime Museum

. lines & profile
1827
National Maritime Museum

Barham (1811). Scale: 1:48. Plan showing the inboard profile for 'Barham' (1811), a 74-gun Third Rate, two-decker, as cut down to a 50-gun Fourth Rate Frigate at Woolwich Dockyard. Signed by Oliver Lang [Master Shpwright, Woolwich Dockyard, 18
19 January 1827
National Maritime Museum

Calcutta (1831). Scale: 1:48. Plan showing the body plan, sheer lines, and longitudinal half-breadth proposed (and approved) for Calcutta (1831), an 80-gun, Second Rate, two-decker. A copy was sent to Bombay on 31 October 1827. Signed by Robert Seppings
3 October 1827
National Maritime Museum

Daphne (cancelled 1832) and Porcupine (cancelled 1832). Scale 1:48. Plan showing the inboard profile plan for Daphne (cancelled 1832) and Porcupine (cancelled 1832), both 28-gun, Sixth Rate Sloops. Signed R[obert] Seppimgs (Surveyor of the Navy)
28th June 1827
National Maritime Museum

Daphne (cancelled 1832), Porcupine (cancelled 1832). Scale 1:48. Plan showing the lower deck plan with platforms, for building Daphne (cancelled 1832) and Porcupine (cancelled 1832), both 28-gun, Sixth Rate Sloops, at Plymouth Dockyard. The pan also has a
28th June 1827
National Maritime Museum

Tyne (1826), Alarm (cancelled 1832), Conway (1832), Imogene (1831). Scale 1:48. Plan showing the stern quater galleries for ships similar to Tyne (1826), Alarm (cancelled 1832), Conway (1832), Imogene (1831), all 28-gun, Sixth Rate vessel.
circa. February 1827
National Maritime Museum

Tyne (1826). Scale 1:48. Plan showing hold and sections illustrating the distribution of ballast and stowage for Tyne (1826), a 28-gun, Sixth Rate vessel in the second Experimental Cruise 14th June 1827. Ballast has colour code reference. NMM, Progess Bo
Circa June 1827
National Maritime Museum

Tyne (1826). Scale 1:48. Plan showing the hold section, illustrating the ballast layout for July 1828 for Tyne (1826), a 28-gun, Sixth Rate vessel. The plan includes a table of weight for tanks, cables, and anchors. NMM, Progess Book, volume 6, folio 54
circa July 1828
National Maritime Museum

Waterloo (fl.1827). Scale: 1:48. Plan showing the body plan, ticked outline of the stern board, sheer lines, and longitudinal half-breadth for Waterloo (fl.1827), an 82-gun Second Rate, two-decker belonging to 'His Netherlands Majesty'. Signed
24 April 1827
National Maritime Museum

Proposed iron nippers on chain cables (1827). Scale: 1:3 and 1:24. Plan showing the elevation of the fore part of a flush-deck 18-gun Sloop illustrating the use of the iron nippers on the chain cables, and a diagram of the nipper open, closed, and in sec
20 February 1827
National Maritime Museum

Ballast for a 60 gun Frigate; Winchester (1822). Scale: 1:48. Plan showing a part plan of the hold for a 60-gun Frigate, similar to the Winchester (1822), a 60-gun, Fourth Rate Frigate, illustrating the stowage of ballast. Plan includes a code of explan
March 1827
National Maritime Museum

Tyne (1826). Scale 1:48. Plan showing the inboard profile plan for Tyne (1826), a 28-gun Sixth Rate vessel built and fitted at Woolwich Dockyard. Signed O.Lang (Master Shipwright)
14 April 1827
National Maritime Museum

Tyne (1826). Scale 1:48. Plan showing the lower deck plan, showing the fore & aft platforms for Tyne (1826), as a 28-gun, Sixth Rate vessel as built and fitted at Woolwich Dockyard. Signed O.Lang (Master Shipwright)
14th April 1827
National Maritime Museum

Tyne (1826). Scale 1:48. Plan showing the quater deck and forecastle for Tyne (1826), as a 28-gun, Sixth Rate vessel as built and fitted at Woolwich Dockyard. Signed O.Lang (Master Shipwright)
14th April 1827
National Maritime Museum

Tyne (1826). Scale 1:48. Plan showing the upper deck plan for Tyne (1826), as a 28-gun, Sixth Rate vessel as built and fitted at Woolwich Dockyard. Signed O.Lang (Master Shipwright)
14th April 1827
National Maritime Museum

'Revenge' (1805). Scale: 1:120. Plan showing the ballast and ground tier, and the middle and upper tier of the hoild for 'Revenge' (1805), a 74-gun Third Rate, two-decker. The plan illustrates the way the method of stowage compensated
10 May 1827
National Maritime Museum

35 ft Commissioners' Cutter. Scale: 1:24. Plan showing the rig and sail elevation for a 12 oared, 35 ft Commissioners' Cutter or Pay Boat. Signed J. Nolloth [Master Shipwright, Portsmouth Dockyard, 1823-1835].
Dated: 12 June 1827
National Maritime Museum

37 ft Commissioners' Barge. Scale: 1:24. Plan showing the rig and sail elevation for a 14 oared, 37 ft Commissioners' Barge. Signed J. Nolloth [Master Shipwright, Portsmouth, 1823-1835].
Dated: 12 June 1827
National Maritime Museum
