'Boyne' (1810); 'Union' (1811). Scale: 1:48. Plan showing the gun deck (lower deck) for 'Boyne' (1810), and later for 'Union' (1811), both 98-gun Second Rate, three-decker, building at Portsmouth and Plymouth Dockya
January 1808
National Maritime Museum

'Illustrious' (1803); 'Albion' (1802); 'Hero' (1803); 'Fame' (1805). Scale: 1:48. Plan showing the inboard profile for 'Illustrious' (1803), 'Albion' (1802), 'Hero' (1803), and 'Fa
April 1800
National Maritime Museum

'Illustrious' (1803); 'Albion' (1802); 'Hero' (1803); 'Marlborough' (1807); 'York' (1807); 'Hannibal' (1810); 'Sultan' (1807); 'Royal Oak' (1809); 'Victorious' (1808
31 January 1800
National Maritime Museum

'Leda' (1800); 'Shannon' (1806); 'Leonidas' (1807); 'Surprise' (1812); 'Lacedemonian' (1812); 'Tenedos' (1812); 'Lively' (1804); 'Trinocomalee' (1817); 'Amphitrite'
9 July 1796
National Maritime Museum

'Sceptre' (1802); 'Repulse' (1803); 'Eagle' (1804). Scale: 1:48. Plan showing the gun (lower) deck for 'Sceptre' (1802), 'Repulse' (1803) and 'Eagle' (1804), all 74-gun Third Rate, two deckers.
Circa May 1800
National Maritime Museum

'Sceptre' (1802); 'Repulse' (1803); 'Eagle' (1804). Scale: 1:48. Plan showing the orlop deck with fore and aft platforms for 'Sceptre' (1802), 'Repulse' (1803) and 'Eagle' (1804), all 74-gun Thir
Circa May 1800
National Maritime Museum

'Sceptre' (1802); 'Repulse' (1803); 'Eagle' (1804). Scale: 1:48. Plan showing the quarterdeck and forecastle for 'Sceptre' (1802); 'Repulse' (1803); 'Eagle' (1804), all 74-gun Third Rate, two-dec
Circa May 1800
National Maritime Museum

'Sceptre' (1802); 'Repulse' (1803); 'Eagle' (1804). Scale: 1:48. Plan showing the upper deck for 'Sceptre' (1802), 'Repulse' (1803) and 'Eagle' (1804), all 74gun Third Rate two deckers.
Circa May 1800
National Maritime Museum

'Sceptre' (1802); 'Repulse' (1803); 'Eagle' (1804); 'Belleisle' (1819); 'Malabar' (1818); 'Talavera' (1818). Scale: 1:48. Plan showing the body plan, sheer lines, and longitudinal half-breadth fo
30 January 1800
National Maritime Museum

'Swiftsure' (1804); 'Victorious' (1808). Scale: 1:48. Plan showing the inboard profile for 'Swiftsure' (1804), and later 'Victorious' (1808), both 74-gun Third Rate, two-deckers, to be built at Bucklers Hard by Mess
December 1800
National Maritime Museum

. deck
1800
National Maritime Museum

. deck, orlop
1800
National Maritime Museum

. deck, quarter & forecastle
1800
National Maritime Museum

. figurehead 38 guns, Fifth Rate. NMM, Progress Book, volume 5, folio 275 states that 'Topaze' (1793) arrived at Sheerness Dockyard on 20 September 1799 and was docked on 3 October. She was undocked on 14 October 1799 and sailed on 25 Decembe
1800
National Maritime Museum

. foremast
1800
National Maritime Museum

. frame
1800
National Maritime Museum

. Inboard profile plan
1800
National Maritime Museum

. lines Signed by Thomas Mitchell [Master Shipwright, Sheerness Dockyard, 1795-1801]. NMM, Progress Book, volume 5, folio 253, states that 'Oiseau' arrived at Sheerness Dockyard on 11 June 1800 and was docked on 24 June. She was undocked on 5
Circa 1800
National Maritime Museum

. lines
1800
National Maritime Museum

. lines & profile Check progress Book for her capture details - 1799 or 1800 and which ship.
1800
National Maritime Museum

. lines & profile NMM, Progress Book, volume 5, folio 739, states that 'Desiree' (1800) arrived at Sheerness Dockyard on 12 July 1800, was docked on 23 August, and sailed on 10 November 1800 having been fitted. The work cost £10,258.
1800
National Maritime Museum

. lines & profile
1800
National Maritime Museum

. Lower deck plan
1800
National Maritime Museum

. platform
1800
National Maritime Museum

. screw cutting machine
1800
National Maritime Museum

. sheer & profile
1800
National Maritime Museum

. Upper deck plan
1800
National Maritime Museum

Conqueror (1801). Scale: 1:48. Plan showing the plan and section for fitting the magazine to Conqueror (1801), a 74-gun Third Rate, two-decker building at Harwich.
1800
National Maritime Museum

Courageaux (1800). Scale: 1:96. Plan showing the underside beams of the upper deck for Courageaux (1800), a 74-gun Third Rate, two-decker, illustrating the battening for slinging hammocks. Note that eight hammocks are shown in pencil. Signed by John Kn
Circa September 1800
National Maritime Museum

Gannet (1800). Scale: 1:48. Plan showing the body plan with stern board outline, sheer lines with inboard detail and scroll figurehead, and longitudinal half-breadth for Gannet (1800), a 16-gun Brig Sloop purchased in March 1800 from Mr King of Dover and
Circa March 1800
National Maritime Museum

Gannet (1800). Scale: 1:48. Plan showing the lower deck and hold, and upper deck for Gannet (1800), a 16-gun Brig Sloop purchased in March 1800 from Mr King of Dover and completed at Chatham Dockyard. Initialled by John Henslow [Surveyor of the Navy, 17
Circa March 1800
National Maritime Museum

Helden (1799) ex Dutch Heldin (1796). Scale 1:48. Plan showing the quarter deck and forecastle for Helden (1799), a captured Dutch Frigate, as taken off as fitted at Deptford Dockyard, a 28-gun, Sixth Rate Frigate. Initialled E.P.T. (Master Shipwright, D
October 1800
National Maritime Museum

Helden (1799), ex Dutch Helden (1796). Scale 1:48. Plan showing the upper deck plan for Helden (1799), a captured Dutch Frigate, as taken off and fitted at Deptford Dockyard, a 28-gun, Sixth Rate Frigate. Initialled E.P.T. (Master Shipwright, Deptford Do
October 1800
National Maritime Museum

Helden (1799), ex Dutch Helden (1796). Scale 1:48. Plan showing thebody plan, sternboard outline with decoration detail, sheer lines with inboard detail and stern decoration and figurehead, and longitudinal half breadth for Helden (1799), a captured Dutch
31st October 1800
National Maritime Museum

Heldin (1799) ex Dutch Heldin (1796). Scale 1:48. Plan showing the lower deck plan for Helden (1799), a captured Dutch Frigate, as taken off and fitted at Deptford Dockyard, a 28-gun, Sixth Rate Frigate. Initialled E.T [Edward Tippet] (Master Shipwright,
October 1800
National Maritime Museum

Jamaica (1798) [ex French, Percante (1795)]. Plan showing the sheer lines with one water line, also with inboard detail alterations pproposed and approved for repairing and fitting Jamaica (1798) [ex Percante (1795)], as captured French Sixth Rate as tak
January 1800
National Maritime Museum

Raven (captured 1799). Scale: 1:48. Plan showing the lower deck for Raven (captured 1799), a captured French Brig, as fitted as an 18 gun Brig Sloop at Plymouth Dockyard. Signed by John Marshall [Master Shipwright, Plymouth Dockyard, 1795-1801].
October 1800
National Maritime Museum

Scout (captured 1800). Scale: 1:48. Plan showing the body plan with stern board outline, sheer lines with inboard detail and figurehead, and longitudinal half-breadth for Scout (captured 1800), a captured French corvette, as fitted as a 20-gun Ship Sloop
December 1800
National Maritime Museum

Scout (captured 1800). Scale: 1:48. Plan showing the lower deck with fore & aft platforms for Scout (captured 1800), a captured French corvette, as fitted as a 20-gun Ship Sloop. Signed by John Marshall [Master Shipwright, Plymouth Dockyard, 1795-18
December 1800
National Maritime Museum

Scout (captured 1800). Scale: 1:48. Plan showing the upper deck for Scout (captured 1800), a captured French corvette, as fitted as a 20-gun Ship Sloop. Signed by John Marshall [Master Shipwright, Plymouth Dockyard, 1795-1801]
December 1800
National Maritime Museum

Spencer (1800). Scale: 1:48. Plan showing the launching arrangements at Bucker's Hard, Beaulie, for Spencer (1800), a 74-gun, two-decker. The reverse has the measurements of the Spenser comparing the contract to the 'as built' dimensions.
May 1800
National Maritime Museum

45ft Chain Lighter (1800). Scale: 1:32. A plan showing the body plan, sheer lines, and longitudinal half-breath for a forty-five foot chain lighter (1800). Signed by Henry Peake [Master Shipwright, Portsmouth Dockyard, 1799-1803; later Surveyor of the
19 January 1800
National Maritime Museum

'Illustrious' (1803). Scale 1:48. Plan showing the body plan, sheer lines with alterations to the gunport positions, and longitudinal half-breadth for 'Illustrious' (1803), a 74-gun Third Rate, two-decker building at Rotherhithe by Mes
14 February 1800
National Maritime Museum

100ft Flat-Bottomed Mud Barges (circa 1800). Scale: 1:96. A plan showing the plan, elevation and sections for two different designs of 100ft flat-bottomed mud barges (circa 1800), illustrating the different methods of carrying and discharging soil excavat
circa May 1800
National Maritime Museum

100ft Flat-Bottomed Mud Barges (no date). Scale: 1:96. A plan showing a section, constructional profile, and deck plan for two proposed 100ft flat-bottomed mud barges (no date) of different designs for transporting and depositing soil dredged by a steam
13 May 1800
National Maritime Museum

30 ft Pinnace for the Commissioners of the Navy. Scale: six inches to the foot (Graduated Bar Scale). Plan showing the body plan, sheer lines with some inboard detail, and longitudinal half-breadth with deck details for an 8-oared 30 ft Pinnace for the u
Annotation dated: June 1800
National Maritime Museum

'Swiftsure' (1804); 'Victorious' (1808). Scale: 1:48. Plan showing the body plan, sheer lines, and longitudinal half-breadth proposed (and approved) for 'Swiftsure' (1804) and 'Victorious' (1808), both 74-gun Third
1 September 1800
National Maritime Museum

Halifax (captured 1797). Scale: 1:48. Plan showing the inboard profile with figurehead for Halifax (captured 1797), a captured French privateer, as taken off prior to being fitted as a 12-gun Armed Brig. Halifax was originally given the name 'Mary&
October 1800
National Maritime Museum

Halifax (captured 1797). Scale: 1:48. Plan showing the upper deck for Halifax (captured 1797), a captured French privateer, as taken off prior to being fitted as a 12-gun Armed Brig. Halifax was originally given the name 'Mary' until the Admir
October 1800
National Maritime Museum

Raven (captured 1799). Scale: 1:48. Plan showinf the upper deck for Raven (captured 1799), a captured French Brig, as fitted as an 18 gun Brig Sloop at Plymouth Dockyard. Signed by John Marshall [Master Shipwright, Plymouth Dockyard, 1795-1801].
October 1800
National Maritime Museum

Raven (captured 1799). Scale: 1:48. Plan showing the body plan with stern board outline, sheer lines with inboard detail and figurehead, and longitudinal half-breadth for Raven (captured 1799), a captured French Brig, as fitted as an 18 gun Brig Sloop at
October 1800
National Maritime Museum
