'Neptune' (1797); 'Ocean' (1805); 'Temeraire' (1798). Scale 1:48. Plan showing the body plan, sheer lines, and longitudinal half-breadth for 'Neptune' (1797), and later for 'Temeraire' (1798) and 'Que
6 July 1790
National Maritime Museum

. Inboard profile plan
1790
National Maritime Museum

. Inboard profile plan
1790
National Maritime Museum

. lines & profile This is the captured French Frigate. Not found in Progress Book. Something to do with July 1790, possibly at Sheerness Dockyard.
1790
National Maritime Museum

. lines & profile
1790
National Maritime Museum

. lines & profile
1790
National Maritime Museum

. lines & profile
1790
National Maritime Museum

. Lower deck plan
1790
National Maritime Museum

. ventilator
1790
National Maritime Museum

Antelope (1802). Scale: 1:48. Plan showing the body plan, sheer lines, and longitudinal half-breadth for Antelope (1802), a 50-gun Fourth Rate, two-decker.
Circa June - early July 1790
National Maritime Museum

Antelope (1802). Scale: 1:48. Plan showing the body plan, sheer lines, and longitudinal half-breadth proposed (and approved) for Antelope (1802), a 50-gun Fourth Rate, two-decker.
29 April 1790
National Maritime Museum

Gorgon (1785); Charon (1783). Scale: 1:48. Plan showing the longitudinal half-breadth of the Gorgon (1785), a 44-gun Fifth Rate, two-decker, as fitted as a troopship, and with alterations for fitting the Charon (1783), a 44-gun Fifth Rate, two-decker, po
24 July 1790
National Maritime Museum

Neptune (1797). Scale 1:48. Plan showing the body plan, sheer lines with stern quarterdeck decoration, and longitudinal half-breadth proposed (and approved) for 'Neptune' (1797), a 98-gun Second Rate, three-decker.
29 April 1790
National Maritime Museum

Serpent (1789). Scale: 1:48. Plan showing the body plan, stern board with decoration and name on the stern counter, sheer lines with figurehead, and longitudinal half-breadth for Serpent (1789), a 16-gun Ship Sloop with quarterdeck and forecastle, as bui
13 February 1790
National Maritime Museum

Serpent (1789). Scale: 1:48. Plan showing the lower deck and fore & aft platforms for Serpent (1789), a 16-gun Ship Sloop as built at Plymouth. Signed by Thomas Pollard [Master Shipwright, Plymouth Dockyard, 1784-1793].
13 February 1790
National Maritime Museum

57ft Mooring Lighter (no date). Scale: 1:48. A plan showing the body plan, sheer lines with some inboard detail, longitudinal half-breadth combined with a longitudinal half-breadth deck plan, for a proposed 57ft Mooring Lighter. Signed by Edward Sison
18 October 1790
National Maritime Museum

Tartar (1757). Scale 1:48. Plan showing sheer lines and only one water line for Tartar (1757), a 28-gun, Sixth Rate Frigate, as being altered during repairs at Chatham by Mr Nicholson's Yard. The decks were raised, as shown by the ticked red lines. A
12th November 1790
National Maritime Museum
