'Cumberland' (1774). Scale 1:48. Plan showing the body plan with sternboard decoration, sheer lines with inboard detail and stern quarter decoration and figurehead, and longitudinal half-breadth for 'Cumberland' (1774), a 74-gun, Third
26 May 1774
National Maritime Museum

'Duke' (1777); 'Saint George' (1785). Scale: 1:48. Plan showing the sheer lines with figurehead, and longitudinal half-breadth for 'Duke' (1777), built at Plymouth Dockyard, and for Saint 'George' (1785) built at Po
circa August 1774
National Maritime Museum

'Duke' (1777); 'Sant George' (1785); 'Glory' (1788). Scale: 1:48. Plan showing the inboard profile for 'Duke' (1777) and 'Glory' (1788), and with an altered bowsprit for 'Saint George' (1785), al
circa April 1774
National Maritime Museum

'Hector' (1774). Scale: 1:48. Plan showing the body plan with stern board decoration, sheer lines with inboard detail and figurehead, and longitudinal half-breadth for 'Hector' (1774), a 74-gun Third Rate, two-decker. The plan may repr
Circa May to July 1774
National Maritime Museum

'Vigilant' (1774). Scale: 1:48. Plan showing the inboard profile for 'Vigilant' (1774), a 64-gun Third Rate, two-decker building at Bucklers Hard by Messrs Henry and Anthony Adams.
22 September 1774
National Maritime Museum

'Vigilant' (1774). Scale: 1:48. Plans showing the body plan, stern board decoration, sheer lines with decoration detail and figurehead, and longitudinal half-breadth for 'Vigilant' (1774), a 64-gun Third Rate, two-decker, as built by M
6 October 1774
National Maritime Museum

. deck
1774
National Maritime Museum

. lines & profile
1774
National Maritime Museum

Centurion (1774). Scale: 1:48. Plan showing the body plan with stern board detail, sheer lines with inboard detail, and longitudinal half-breadth for Centurion (1774), a 50-gun Fourth Rate, two-decker, as built by Barnard & Turner at Harwich. She wa
Circa June 1774
National Maritime Museum

Centurion (1774). Scale: 1:48. Plan showing the roundhouse, quarterdeck, forecastle, upper deck, lower deck, and orlop deck with platforms for Centurion (1774), a 50-gun Fourth Rate, two-decker, as built at Harwich. Note that the upper and lower decks a
Circa June 1774
National Maritime Museum

Ceres (1777). Scale: 1:48. Plan showing the body plan, sheer lines with some midship section framing, longitudinal half-breadth for Ceres (1777), an 18-gun Ship Sloop. The plan states that she was based on the sheer of the captured French Pomona (captur
5 August 1774
National Maritime Museum

Orpheus (1774). Scale 1:48. Plan showing the body plan with stern board detail, sheer lines with inboard detail, and longitudinal half-breadth for Orpheus (1774), a 32-gun, Fifth Rate Frigate, as built at Harwich by Messrs Barnard and Turner.
1774
National Maritime Museum

Surprize (1774). Scale 1:48. Plan showing the body plan with sternboard decoration, sheer lines,with figurehead, and longitudinal half breadth as proposed and approved for Surprize (1774), a 28-gun, Sixth Rate Frigate, as built and fitted at Woolwich Dock
1774
National Maritime Museum
