Carysfort (1766), Levant (1758). Scale 1:96. Plan showing the body plan, sheer lines with inboard detail, longitudinal half breadth for Levant (1758) and Carysfort (1766), both 28-gun, Sixth Rate Frigates. Date unknown as Carysfort not launched until 1766
c. 1766
National Maritime Museum

Egmont (1768). Scale: 1:48. Plan showing the inboard profile, with later alterations, proposed (and approved) for 'Egmont' (1768), a 74-gun Third Rate, two-decker, building at Deptford Dockyard.
Circa October 1767
National Maritime Museum

Grafton (1771); Fortitude (1780). Scale: 1:48. Plan showing the body plan, sheer lines, and longitudinal half-breadth proposed (and approved) for building Grafton (1771), and with approved alterations dated 1778 for Fortitude (1780), both 74-gun Third Rat
22 September 1767
National Maritime Museum

Monmouth (1772). Scale: 1:48. Plan showing the body plan, sheer lines, and longitudinal half-breadth proposed (and approved) for building Monmouth (1772), a 64-gun Third Rate, two-decker. The plan includes a mast and yard dimension table. Signed by Joh
22 September 1767
National Maritime Museum

Princess Royal (1773). Scale 1:48. Plan showing the body plan, sheer lines with some decoration detail, and longitudinal half-breadth proposed (and approved) for 'Princess Royal' (1773), a 90-gun Second Rate, three-decker, to be build Portsmouth
22 September 1767
National Maritime Museum

Salisbiry (1769); Centurion (1774). Scale: 1:48. Plan showing the upper deck proposed for Salisbury (1769), and later used for Centurion (1774), both 50-gun Fourth Rate, two-deckers.
Circa October 1767
National Maritime Museum

Salisbury (1769); Centurion (1774). Scale: 1:48. Plan showing the gun deck (lower deck) proposed for Salisbury (1769), and later used for Centurion (1774), both 50-gun Fourth Rate, two-deckers.
Circa October 1767
National Maritime Museum

Salisbury (1769); Centurion (1774). Scale: 1:48. Plan showing the inboard profile proposed (and approved) for Salisbury (1769), a 50-gun Fourth Rate, two-decker. Alterations were sent in May 1770 relating to fitting an awning and an additional two cabin
Circa October 1767
National Maritime Museum

Salisbury (1769); Centurion (1774). Scale: 1:48. Plan showing the orlop deck with fore & aft platforms for Salisbury (1769) and later for Centurion (1774), both 50-gun Fourth Rate, two-deckers.
Circa October 1767
National Maritime Museum

Salisbury (1769); Centurion (1774). Scale: 1:48. Plan showing the quarterdeck and forecastle proposed for Salisbury (1769), and later used for Centurion (1774), both 50-gun Fourth Rate, two-deckers. The quarterdeck was altered to an order dated 18 May 1
Circa October 1767
National Maritime Museum
