Conquestador (captured 1762). Scale: 1:48. Plan showing the midship section with sternboard outline, the body plan, sheer lines with inboard detail, and longitudinal half-breadth for Conquestador (captured 1762), a captured Spanish Fourth Rate. The plan
Circa 1763 - 1764
National Maritime Museum

28 ft Cutter. Scale: 1:16. Plan showing the body plan, inboard profile, and longitudinal half-breadth with inboard detail, for an 8-oared, 28 ft Cutter, as taken off at Woolwich Dockyard.
Dated: 1764
National Maritime Museum

Carysfort (1766). Scale 1:48. Plan showing the body plan, sheer lines, longitudinal half breadth proposed and approved for building Carysfort (1766), a 28-gun, Six th Rate Frigate building at Sheerness Dockyard, in the design room of Trent (1757, sold 176
14th February 1764
National Maritime Museum

56ft Mooring Lighter (no date). Scale: 1:32. A plan showing the body plan, section, inboard profile, and deck plan with longitudinal half-breadth for a fifty-six foot mooring lighter to be built at Sheerness Dockyard. Signed by John Williams [Master S
November 1764
National Maritime Museum
