'Hayling' (1760). Scale: 1:48. A plan showing the body plan with stern board outline, inboard profile with scroll head, and longitudinal half-breadth with deck detail for the 'Hayling' (1760), a single-masted sixty-six foot timber hoy
circa 1759-1760
National Maritime Museum

'Monarch' (1765); 'Ramillies' (1763); 'Terrible' (1762); 'Russell' (1764); 'Invincible' (1765); 'Magnificent' (1766); 'Prince of Wales' (1765); 'Marlborough' (1767); 'Rob
Circa July 1760
National Maritime Museum

. deck
1760
National Maritime Museum

. lines
1760
National Maritime Museum

. lines
1760
National Maritime Museum

. lines
1760
National Maritime Museum

. lines & profile
1760
National Maritime Museum

. Lines. There is a letter and envelope marked ZAZ7450.1 and ZAZ7450.2, which can be viewed via the grey toggle to the right of the WHOLE field.
1760
National Maritime Museum

Albion (1763); Fortitude (1780); Irresistable (1782); Grafton (1771); Alcide (1779). Scale: 1:48. Plan showing the body plan, sheer lines, and longitudinal half-breadth for Albion (1763) a 74-gun Third Rate, two-decker. The plan was later used for buildin
Circa June 1760
National Maritime Museum

Albion (1763); Irresistable (1782). Scale: 1:48. Plan showing the body plan, sheer lines, and longitudinal half-breadth for Albion (1763), and later, by Admiralty Order dated 6 July 1778, for Irresistible (1782), both 74-gun Third Rate, two-decker. Signe
23 April 1760
National Maritime Museum

Centaur (captured 1759). Scale: 1:48. Plan showing the body plan, sternboard decoration detail with name on the counter in a cartouche, sheer lines with inboard detail and figurehead, and longitudinal half-breadth for Centaur (captured 1759), a captured F
Circa December 1759
National Maritime Museum

Centaur (captured 1759). Scale: 1:48. Plan showing the inboard profile for Centaur (captured 1759), a captured French Third Rate. The plan illustrates the ship as altered and fitted to a British layout as a 74-gun Third Rate, two-decker, at Chatham Dockya
Circa mid 1760
National Maritime Museum

Ferret (1760). Scale: 1:48. Plan showing the body plan, sheer lines with inboard detail and fiddle scroll figurehead, and longitudinal half-breadth for building the Ferret (1760), a 14-gun Ship Sloop. A copy of this plan was sent to Mr Stanton on 17 May
May 1760
National Maritime Museum

Ferret (1760). Scale: 1:48. Plan showing the quarterdeck, forecastle, upper deck, and lower deck with platforms for fitting the Ferret (1760), a 14-gun Ship Sloop at Rotherhithe by Mr Stanton. A copy of the plan was sent to Mr Stanton on 10 September 17
September 1760
National Maritime Museum

Martin (1761); Beaver (1761). Scale: 1;48. Plan showing the body plan, sheer lines with inboard detail and longitudinal half-breadth for building Martin (1761) and Beaver (1761), both 14-gun Ship Sloops. Signed by William Bately [Surveyor of the Navy, 1
May 1760
National Maritime Museum

Mermaid (1761) Hussar (1763) , Soleby (1763). Scale 1:48. Plan showing the body plan, sheer lines and longitudinal half breadth as proposed and approved for Mermaid (1761), a 28-gun, Fifth Rate Frigate, for building at Hull by Mr Blaydes, and later for Hu
circa. May 1760
National Maritime Museum

Mermaid (1761), Hussar (1763), Soleby (1763). Scale 1:48. Plan showing the Inboard profile plan as proposed and approved for Mermaid (1761), a 28-gun, Fifth Rate Frigate, for building at Hull by Mr Blaydes, and later for Hussar (1763) and Soleby (1763), a
August 1760
National Maritime Museum

Mermaid (1761). Scale 1:48. Plan showing the body plan, sheer lines and longitudinal half breadt as proposed and approved for Mermaid (1761), a 28-gun, Fifth Rate Frigate, for building at Hull by Mr Blaydes. Signed by Thomas Slade (Surveyor of the Navy) a
1760
National Maritime Museum

Otter (1767). Scale: 1:48. Plan showing the quarterdeck, forecastle, upper deck, lower deck, and fore & after platforms proposed (and approved) for Otter (1767), a 14-gun Ship Sloop to be built at Deptford Dockyard.
Circa June 1760
National Maritime Museum

Romney (1762). Scale: 1:48. Plan showing the body plan, sheer lines, and longitudinal half-breadth for Romney (1762), a 50-gun Fourth Rate, two-decker. The plan includes alterations to the roundhouse and solid bulwarks to the poop deck, which were added
Circa November 1760
National Maritime Museum

Senegal (1760). Scale: 1:48. Plan showing the body plan with stern board outline, sheer lines with inboard detail, and longitudinal half-breadth for Senegal (1760), a 14-gun Ship Sloop. The plan includes sweep ports and swivel gun mounts along the broad
Circa 1760
National Maritime Museum

Senegal (1760). Scale: 1:48. Plan showing the body plan, sheer lines with inboard detail, and longitudinal half-breadth for building Senegal (1760), a 14-gun Ship Sloop. The plan refers to her as a frigate to be built at Rotherhithe by Mr Henry Bird. S
circa May 1760
National Maritime Museum

Senegal (1760). Scale: 1:48. Plan showing the fore & aft platforms for Senegal (1760), a 14-gun Ship Sloop.
Circa 1760
National Maritime Museum

Speedwell (fl.1760). Scale: 1:48. Plan showing the body plan with half stern board outline, sheer lines with inboard detail, longitudinal half-breadth, and deck plan for Speedwell (fl.1760), a 58ft Armed Cutter, as taken off at Mr Bird's Dock in Jun
Circa June 1760
National Maritime Museum

Temeraire (1759). Scale: 1:48. Plan showing the body plan with stern board outline and decoration detail, sheer lines with inboard detail and figurehead, and longitudinal half-breadth for Temeraire (1759), a captured Third Rate, as taken off at Portsmouth
5 March 1760
National Maritime Museum

Ocean (1761). Scale 1:48. A plan showing the orlop deck with platforms for 'Ocean' (1761), a 90-gun Second Rate, three-decker.
June 1760
National Maritime Museum

Ocean (1761). Scale 1:48. A plan showing an inboard profile for 'Ocean' (1761), a 90-gun Second Rate, three-decker, building at Chatham Dockyard.
June 1760
National Maritime Museum

Ocean (1761). Scale 1:48. A plan showing basic sheer lines for 'Ocean' (1761), a 90-gun Second Rate, three-decker, building at Chatham Dockyard.
June 1760
National Maritime Museum

Ocean (1761). Scale 1:48. A plan showing the gun deck (lower deck) for 'Ocean' (1761), a 90-gun Second Rate, three-decker.
June 1760
National Maritime Museum

Ocean (1761). Scale 1:48. A plan showing the middle deck plan for 'Ocean' (1761), a 90-gun Second Rate, three-decker.
June 1760
National Maritime Museum

Ocean (1761). Scale 1:48. A plan showing the quarterdeck and forecastle for 'Ocean' (1761), a 90-gun Second Rate, three-decker.
June 1760
National Maritime Museum

Ocean (1761). Scale 1:48. A plan showing the upper deck for 'Ocean' (1761), a 90-gun Second Rate, third-decker.
June 1760
