. Scale 1:19.2. A plan showing the body plan, sheer lines, and longitudinal plan for an 18ft bark canoe brought back to England for Lord Anson by Captain Henry Barnsley of HMS America (1749), in November 1750. The plan includes the outline of one of the
1750
National Maritime Museum

Cambridge (1755). Scale: 1:48. Plan showing the body plan, sheer lines, and longitudinal half-breadth for Cambridge (1755), a modified 1745 Establishment 80-gun Third Rate, three-decker. Signed by Joseph Allin [Surveyor of the Navy, 1749-1755].
July 1750
National Maritime Museum

Dunkirk (1754); Achilles (1757); America (1757). Scale: 1:48. Plan showing the body plan, sheer lines with inboard detail, and longitudinal half-breadth for Dunkirk (1754), a 60-gun Fourth Rate, two-decker. A copy of the plan was sent to merchant yards
July 1750
National Maritime Museum

Montague (1757). Scale: 1:48. Plan showing the body plans, sheer lines, and longitudinal half-breadth proposed (and approved) for building the Montague (1757), a 60-gun Fourth Rate, two-decker. This replaced the previous ship called Montague (1714). Th
July 1750
National Maritime Museum

Namur (1756). Scale: 1:48. Plan showing the body plan, sheer lines, and longitudinal half-breadth for building Namure (1756), a 90-gun Second Rate, three-decker, at Chatham Dockyard. The plan includes alterations to the upper decks in red from the Surveyo
circa July 1750
National Maritime Museum
