'Blenheim' (1709). Scale 1:96. Plan showing an incomplete plan of middle deck, lower deck, and orlop deck for 'Blenheim' (1709), a 90-gun Second Rate, three-decker, as converted to a hospital ship. 'Blenheim' was converted to
circa 1740 or 1755
National Maritime Museum

. deck NMM, Progress Book, volume 2, folio 540, states that 'Peregrina' was launched as the 'Merlin', and that the 'Pembroke Prize' was launched as the 'Vulture'. The plan does not relate to the ex-Spanish ship &#
1743
National Maritime Museum

. lines This plan relates to the new-builds which originally hads the names of the ships they replaced - esp. the Rupert's Prize and Pembroke's Prize. Peregrina was launched as Merlin Galgo was launched as Swallow NMM, progress Book, volume 2,
1743
National Maritime Museum

. lines & profile
1743
National Maritime Museum

Harwich (1743); Colchester (1744); Falkland (1744); Chester (1744); Winchester (1744); Portland (1744); Rochester (1749); Gloucester (1745); Norwich (1745); Ruby (1745); Advice (1745). Scale: 1:48. Plan showing the lower deck for Harwich (1743), Colchest
30 June 1743
National Maritime Museum

Harwich (1743); Colchester (1744); Falkland (1744); Chester (1744); Winchester (1744); Portland (1744); Rochester (1749); Gloucester (1745); Norwich (1745); Ruby (1745); Advice (1745); Salisbury (1746); Colchester (1746). Scale: 1:48. Plan showing the or
30 June 1743
National Maritime Museum

Harwich (1743); Colchester (1744); Falkland (1744); Chester (1744); Winchester (1744); Portland (1744); Rochester (1749); Gloucester (1745); Norwich (1745); Ruby (1745); Advice (1745); Salisbury (1746); Colchester (1746). Scale: 1:48. Plan showing the up
30 June 1743
National Maritime Museum

Panther (1746). Scale: 1:48. Plan showing the body plan, stern board outline with some decoration detail, sheer lines, and longitudinal half-breadth proposed (and approved) for Panther (1746), a 1741 Establishment, 50-gun, Fourth Rate, two-decker. This
November 1743
National Maritime Museum

Panther (1746). Scale: 1:48. Plan showing the body plan, stern board outline, sheer lines, and longitudinal half-breadth proposed for Panther (1743), a 50-gun Fourth Rate, two-decker.
28 June 1743
National Maritime Museum

Princess Louisa (1744); Defiance (1744). Scale: 1:48. Plan showing the gun deck (lower deck) for Princess Louisa (1744) and Defiance (1744), both 1741 Establishment 60-gun Fourth Rates.
19 October 1743
National Maritime Museum

Princess Louisa (1744); Defiance (1744). Scale: 1:48. Plan showing the orlop deck with fore & aft platforms for Princess Louisa (1744) and Defiance (1744), both 1741 Establishment 60-gun Fourth Rates.
19 October 1743
National Maritime Museum

Princess Louisa (1744); Defiance (1744). Scale: 1:48. Plan showing the quarterdeck and forecastle for Princess Louisa (1744) and Defiance (1744), both 1741 Establishment 60-gun Fourth Rates.
19 October 1743
National Maritime Museum

Princess Louisa (1744); Defiance (1744). Scale: 1:48. Plan showing the upper deck for Princess Louisa (1744) and Defiance (1744), both 1741 Establishment 60-gun Fourth Rates.
19 October 1743
National Maritime Museum

'Minorca' (1740). Scale: possibly 1:48. A plan showing the body plan, sheer lines with some inboard detail, and longitudinal half-breadth with deck detail, for 'Minorca' (1740), a single-masted ex-Deptford lighter. On the reverse is
circa August 1743
National Maritime Museum

Fly (1732). Scale: 1:48 and 1:96. Plan showing the body plan with stern board outline, sheer lines with inboard detail and figurehead, longitudinal half-breadth and deck plan for the Fly (1732), an 8/10-gun snow-rigged two-masted sloop, as taken off at P
14 November 1743
National Maritime Museum
