'Elizabeth' (1737). Scale: 1:48. Plan showing the body plan, sheer lines, and longitudinal half-breadth for 'Elizabeth' (1737), a 1733 Establishment 70-gun Third Rate, two-decker, as rebuilt at Chatham Dockyard and launched on 29 Novem
Circa November 1737
National Maritime Museum

'Royal Oak' (1741). Scale: 1:48. Plan showing the body plan, sheer lines with deck level outline, and longitudinal half-breadth proposed for 'Royal Oak' (1741), a 1733 Establishment 70-gun Third Rate, two-decker.
March 1737
National Maritime Museum

Princess Mary (1742). Scale: 1:48. Plan showing the body plan, sheer lines with inboard detail, and longitudinal half-breadth for Princess Mary (1742), a 60-gun Fourth Rate, two-decker. Signed by Joseph Allin [Master Shipwright, Portsmouth Dockyard, 172
Circa June 1737
National Maritime Museum

Saint Albans (1737). Scale: 1:48. Plan showing the body plan, stern board with some decoration detail, sheer lines with inboard detail, upper deck details, and longitudinal half-breadth with lower deck details for Saint Albans (1737), a 1733 Establishmen
Circa August-September 1737
National Maritime Museum

Guernsey (1740). Scale: 1:48. Plan showing the body plan, sheer lines, and longitudinal half-breadth proposed (and approved) for Guernsey (1740), a 50-gun Fourth Rate, two-decker. Signed by John Ward [Master Shipwright, Chatham Dockyard, 1732-1752]. N
13 June 1737
